-7-
Service Manual
Receiver Feature Table
Table 1: Receiver Features
FEATURE\MODEL
SP-3235F/UF CT-2707DF/DUF CT-27D32F/UF CT-27D12DF/DUF
Chassis RP341 TP338 QP338 SP338
No. of channels 181 181 181 181
Menu language Eng/Span/Fr Eng/Span/Fr Eng/Span/Fr Eng/Span/Fr
Closed Caption XX X X
V-Chip (USA/CANADA) XX X X
PIP -- 1T 2T ---
75 Ω input XX X X
Remote Model Number EUR511514 EUR511511 EUR7613Z30 EUR7613Z10
Picture tube M80JUA061X M68LGL061X M68LGL061X M68LGL061X
Comb Filter 3 Dig 3 Dig 3 Dig 3 Dig
HEC/VEC (X=BOTH) HEC HEC HEC HEC
V/A norm (X=BOTH) XX X X
Color Temp XX X X
MTS/SAP/DBX XX X X
BASS/BL/TRE Control XX X X
AI Sound XX X X
Surround XX X X
Built-in audio power 5W x 2 (10%) 5W x 2 (10%) 5W x 2 (10%) 5W x 2 (10%)
No. of speakers 22 2 2
A/V in (rear/front) 2(2/0) 3(2/1) 3(2/1) 3(2/1)
S-VHS Input (rear/front) 1/0 1/0 1/0 1/0
Component Input
(Y,Pb,Pr)
11 1 1
FAO/VAO BOTH BOTH BOTH BOTH
EPJ/HPJ/MISC -- HPJ HPJ HPJ
Dimensions mm
(WxDxH) in
770 x 557 x 687
30.3 x 21.9 x 27.4
665 x 554.5 x 594.8
26.2 x 21.8 x 23.4
770 x 537 x 694
30.3 x 21.1 x 27.3
665 x 545 x 595
30.3x 21.4 x 23.4
Weight (kg/lbs) 49.5/109 35/77 49.5/109 35/77
Power source (V/Hz) 120/60 120/60 120/60 120/60
Anode voltage 29.25kV ± 1.25kV 28.30kV ± 1.25kV 28.30kV ± 1.25kV 28.30kV ± 1.25kV
Video input jack
1Vp-p 75Ω, phono
jack
1Vp-p B 75Ω, phono
jack
1Vp-p 75Ω, phono
jack
1Vp-p 75Ω, phono
jack
Audio input jack 500mV RMS 47kΩ 500mV RMS 47kΩ 500mV RMS 47kΩ 500mV RMS 47kΩ
Specifications are subject to change without notice or obligation. Dimensions and weights are approximate.
