Service Manual
Receiver Feature Table
Table 1: Receiver Features
FEATURE\MODEL
CT-36D32F/UF CT-36D12DF/DUF CT-32D32F/UF CT-32D12DF/DUF CT-3207DF/DUF
Chassis JP342 KP342 NP341 TP341 QP341
No. of channels 181 181 181 181 181
Menu language Eng/Span/Fr Eng/Span/Fr Eng/Span/Fr Eng/Span/Fr Eng/Span/Fr
Closed Caption XX XXX
V-Chip (USA/CANADA) XX XXX
PIP 2T --- 2T --- 1T
75 Ω input XX X XX
Remote Model Number EUR7613Z30 EUR7613Z10 EUR7613Z30 EUR7613Z10 EUR511501
Picture tube A90LLD361X A90LLD361X M80JUA061X M80JUA061X M80JUA061X
Comb Filter 3 Dig 3 Dig 3 Dig 3 Dig 3 Dig
HEC/VEC (X=BOTH) HEC HEC HEC HEC HEC
V/A norm (X=BOTH) XX X XX
Color Temp XX XXX
MTS/SAP/DBX XX X XX
BASS/BL/TRE Control XX XXX
AI Sound XX XXX
Surround XX XXX
Built-in audio power 5W x 2 (10%) 5W x 2 (10%) 5W x 2 (10%) 5W x 2 (10%) 5W x 2 (10%)
No. of speakers 22 2 22
A/V in (rear/front) 3(2/1) 3(2/1) 3(2/1) 3(2/1) 3(2/1)
S-VHS Input (rear/front) 1/0 1/0 1/0 1/0 1/0
Component Input
(Y,Pb,Pr)
11 111
FAO/VAO BOTH BOTH BOTH BOTH BOTH
EPJ/HPJ/MISC HPJ HPJ HPJ HPJ HPJ
Dimensions mm
(WxDxH) in
878 x 642 x 764
34.5 x 25.3 x 30.1
878 x 642 x 764
34.6 x 25.3 x 30.1
770 x 536 x 694
30.3 x 21.2 x 27.3
770 x 536 x 694
30.3 x 21.2 x 27.3
770 x 557 x 687
30.3 x 21.9x 27.0
Weight (kg/lbs) 67.51/48.8 67.5/48.8 49.5/109 49.5/109 49.5/109
Power source (V/Hz) 120/60 120/60 120/60 120/60 120/60
Anode voltage 31.50kV ± 1.25kV 31.50kV ± 1.25kV 29.25kV ± 1.25kV 29.25kV ± 1.25kV 29.25kV ± 1.25kV
Video input jack
1Vp-p 75Ω, phono
jack
1Vp-p B 75Ω, phono
jack
1Vp-p 75Ω, phono
jack
1Vp-p 75Ω, phono
jack
1Vp-p 75Ω, phono
jack
Audio input jack 500mV RMS 47kΩ 500mV RMS 47kΩ 500mV RMS 47kΩ 500mV RMS 47kΩ 500mV RMS 47kΩ
Specifications are subject to change without notice or obligation. Dimensions and weights are approximate.
