Panasonic CT-3207DF - Circuit Board Identification

-9-
Service Manual
Board description table
IMPORTANT
When ordering a board, add an “S” after the board suffix application
Example: If order A-Board for CT-27D12DF, should be ordered as:
TNP2AH017AKS
Board
CT-27D12DF
CT-27D12DUF
CT-27D32F
CT-27D32UF
CT-2707DF
CT-2707DUF
CT-32D32F
CT-32D32UF
CT-32D12DF
CT-32D12DUF
A-Board
Main Chassis
TNP2AH017
AK AL AJ BK BL
C-Board
CRT-Board
TNP2AA047
AX AX AX AN AN
Y-Board
PIP-Board
TNPA1059
-- BD BD BD --
Z-Board
Pincushion
TNP2AA010
-- -- -- AE AE
Board
CT-36D32F
CT-36D32UF
CT-36D12DF
CT-36D12DUF
A-Board
Main Chassis
TNP2AH017
CG CH
C-Board
CRT-Board
TNP2AA048
AA AA
Y-Board
PIP-Board
TNP2A1059
BD --
Z-Board
Pincushion
TNP2AA010
AE AE
Board
CT-3207DF
CT-3207DUF
SP-3235F
SP-3235UF
A-Board
Main Chassis
TNP2AH017
BH BJ
C-Board
CRT-Board
TNP2AA047
AN AN
Y-Board
PIP-Board
TNP2A1059
BD BD
Z-Board
Pincushion
TNP2AA010
AE AE
