Panasonic CT-3207DF - Replacement Parts List

-14-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
C360 TACCW101T50V
CAP,C 100PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C364 ECA1CM100B
CAP,E 10UF-16V
CT-36D12DF/DUF CT-36D32F/UF
C366 ECKR2H332KB5
CAP,C 3300PF-K-550V
CT-36D12DF/DUF CT-36D32F/UF
C370 ECKR2H821KB5
CAP,C 820PF-K-500V
CT-36D12DF/DUF CT-36D32F/UF
C371 ECA1CM100B
CAP,E 10UF-16V
CT-36D12DF/DUF CT-36D32F/UF
C401 ECJ2VB1C104K CAP,C .1UF-K-16V
C403 ECA1HM010B CAP,E 1UF-50V
C404 ECA1HM010B CAP,E 1UF-50V
C405 ECSF1EE105VB CAP,E 1.0UF-25V
C407 ECA1CM100B CAP,E 10UF-16V
C409 TCJ2VC1H101J CAP,C 100PF-J-50V
C415 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C451 ECA1HM2R2B CAP,E 2.2UF-50V
C452 ECQB1H473JF3 CAP,P .047UF-J-50V
C453 ECA1VM471B CAP,E 470UF-35V
C454 ECA1VHG221E CAP,E 220UF-35V
C455 ECA1EM222E CAP,E 2200UF-25V
C456 ECCR1H020CC5 CAP,C 2PF-C-50V
C457 ECJ2VB1C104K CAP,C .1UF-K-16V
C458 ECA1CM101B CAP,E 100UF/16V
C459 ECQM1104JZW CAP,P .10UF-J-100V
C502 ECA1CM221B CAP,E 10UF-16V
C503 TCJ2VC1H221J CAP,C 220PF-J-50V
C504 ECQB1H222JF3 CAP,P 2200PF-J-50V
C505 TCJ2VC1H180J CAP,C 18PF-J-50V
C506 ECA1CM471B CAP,E 470UF-16V
C507 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C508 TCJ2VC1H102J CAP,C 1000PF-J-50V
C510 ECCR2H100D5 CAP,C 10PF-D-500V
C511 ECKR2H821KB5 CAP,C 820PF-K-500V
C512 ECKR2H101KB5 CAP,C 100UF-K-500V
C514 ECA1HMR22B CAP,E .22UF-50V
C515 TCJ2YC1H222J CAP,C .022UF-J-50V
C516 TCJ2VC1H391J CAP,C 390PF-J-50V
C517 TCJ2VC1H221J CAP,C 220PF-J-50V
C518 TCJ2VC1H151J CAP,C 150PF-J-50V
C519 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C531 ECA1EM220B CAP,E 22UF-25V
C551 ECA1VM331B CAP,E 330UF-35V
C552 ECA1CM331B CAP,E 330UF-16V
C553 ECA1CM331B CAP,E 330UF-16V
C554 ECKR2H561KB5 CAP,C 560PF-K-500V
C555 ECA2EM220E CAP,E 22UF-250V
C556 ECA1CM102B CAP,E 1000UF/16V
C557 ECKR2H102KB5 CAP,C 1000PF-K-500V
C558 ECA1CM221B CAP,E 10UF-16V
C560 ECEA1HN2R2UB CAP,E 2.2UF-50V
REF
NO.
PART NO. DESCRIPTION
C561 ECKR2H561KB5 CAP,C 560PF-K-500V
C562 ECKR2H561KB5 CAP,C 560PF-K-500V
C563 ECWH12H133JS
CAP,P .013UF-J-1.2KV
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C563 ECWH12H153JS
CAP,P .015UF-J-1.2KV
CT-36D12DF/DUF CT-36D32F/UF
C563 ECWH12H822JS
CAP,P .0082UF-J-1.2KV
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C564 ECWH12H122JS
CAP,P .0012UF-J-1.2KV
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C564 ECWH12H152JS
CAP,P .0015UF-J-1.2KV
CT-36D12DF/DUF CT-36D32F/UF
C564 ECWH12H272JS
CAP,P .0027UF-J-1.2KV
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C565 ECKW3D122JBR
CAP,C 1200PF-J-2KV
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C565 ECKW3D561JBR
CAP,C 560PF-J-2KV
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C565 ECKW3D821JBR
CAP,C 820PF-J-2KV
CT-36D12DF/DUF CT-36D32F/UF
C566 ECKW3D181JBP CAP,C 180PF-J-2KV
C567 ECQM4562JZW
CAP,P 5600PF-J-400V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C568 ECQM2274JZW
CAP,P .27UF-J-200V
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C568 ECQM4473JZW
CAP,P .047UF-J-400V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C569 TACFV2E474J
CAP,M .47UF-J-200V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C569 TACFV2E624J
CAP,M .62UF-J-200V
CT-36D12DF/DUF CT-36D32F/UF
C571 ECA1CM471B CAP,E 470UF-16V
C572 ECA1CM100B CAP,E 10UF-16V
C573 ECA1CM101B CAP,E 100UF/16V
C574 ECKR2H471KB5
CAP,C 470PF-K-500W
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C601 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C603 ECQB1H223JF3 CAP,P .022UF-J-50V
C616 ECJ2VB1C104K CAP,C .1UF-K-16V
C641 ECA1HM100B CAP,E 10UF/50V
REF
NO.
PART NO. DESCRIPTION
