Panasonic CT-3207DF - Page 18

-18-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
C3006 ECA1HM010B CAP,E 1UF-50V
C3007 ECA1CM100B CAP,E 10UF-16V
C3008 ECA1CM100B CAP,E 10UF-16V
C3009 ECA1HM010B CAP,E 1UF-50V
C3010 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3011 ECA1HM010B CAP,E 1UF-50V
C3012 ECA1CM100B CAP,E 10UF-16V
C3013 ECA1CM100B
CAP,E 10UF-16V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
C3014 ECA1HM010B
CAP,E 1UF-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
C3016 ECA1HM010B
CAP,E 1UF-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
C3018 ECA1CM100B CAP,E 10UF-16V
C3019 ECA1CM100B CAP,E 10UF-16V
C3020 ECA1HM010B CAP,E 1UF-50V
C3021 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3022 ECA1HM010B CAP,E 1UF-50V
C3023 ECA1CM100B CAP,E 10UF-16V
C4301 ECA0JM331B
CAP,E 330UF-6.3V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4304 ECEA1CKA100B
CAP,E 10UF-16V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4307 ECEA1CKN100B
CAP,E 10UF-16V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4313 TCJ2VB1H561K
CAP,C 560PF-K-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4314 ECA1HMR47B
CAP,E .47UF-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4315 TCJ2VB1H152K
CAP,C 1500PF-K-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4316 ECA0JM331B
CAP,E 330UF-6.3V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
C4317 TCJ2VF1H103Z
CAP,C .01UF-Z-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4319 TCJ2VC1H391J
CAP,C 390PF-J-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C4320 TCJ2VB1H681K
CAP,C 680PF-K-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C6501 ECA0JM101B CAP,E 100UF-6.3V
C6502 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6504 TCJ2VC1H270J CAP,C 27PF-J-50V
C6507 TCJ2VC1H120J CAP,C 12PF-J-50V
C6510 TCJ2VC1H120J CAP,C 12PF-J-50V
C6511 ECA1HM010B CAP,E 1UF-50V
C6512 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6513 TCJ2VC1H270J CAP,C 27PF-J-50V
C6516 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6517 ECEA1HN010UB CAP,E 1UF/50V
C6518 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6520 ECA1CM100B CAP,E 10UF-16V
C6521 ECA1AM470B CAP,E 47UF-10V
C6522 TCJ2VC1H221J CAP,C 220PF-J-50V
C6523 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6524 ECA1HM010B CAP,E 1UF-50V
C6525 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6526 ECA1CM100B CAP,E 10UF-16V
C6527 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6528 ECA1AM470B CAP,E 47UF-10V
C6529 ECA1CM100B CAP,E 10UF-16V
C6531 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6532 ECJ2VF1H103Z CAP,C .01UF-Z-50V
JS2306 TCJ2VB1H472K CAP,C 4700PF-K-50V
DIODES
D001 ERA15-01V3 DIODE, RECTIFIER
D002 MA165TA5VT DIODE, SWITCHING
D003 MA4056MTA DIODE
D006 MA4330HTA DIODE
D007 ERA15-01V3 DIODE, RECTIFIER
D008 ERA15-01V3 DIODE, RECTIFIER
D009 ERA15-01V3 DIODE, RECTIFIER
D011 MA165TA5VT DIODE, SWITCHING
D014 MA165TA5VT DIODE, SWITCHING
D015 MA700ATA DIODE
D018 MA165TA5VT DIODE, SWITCHING
D351 MA165TA5VT
DIODE, SWITCHING
CT-36D12DF/DUF CT-36D32F/UF
D352 MA165TA5VT
DIODE, SWITCHING
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
