-20-
Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
D3022 MA4110MTA
DIODE, ZENER
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-36D12DF/DUF CT-36D32F/UF
D4301 MA3036HTX
DIODE
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
FUSES
F801 XBA2A00101 FUSE 6.3A 125V
INTEGRATED CIRCUITS
IC001 MN101C46FTH IC MPU
IC002 TVR2AJ126
IC, EEPROM
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
CT-2707DF/DUF CT-3207DF/DUF
SP-3235F/UF
IC002 TVR2AJ127
IC, EEPROM
CT-36D12DF/DUF CT-36D32F/UF
IC003 PIC-37042SR IC, IR RECEIVER
IC005 PQ1R33 IC, VOLTAGE REGULATOR, 3.3V
IC006 PST9128NR IC, RESET
IC101 TA1310BN IC VCJ
IC451 LA7845N IC V-OUT
IC551 AN78M09LB IC VOLTAGE REGULATOR 9V
IC552 AN7805LB IC VOLTAGE REGULATOR, 5V
IC801 PC817X2 IC OPTO ISOLATOR
IC801 STRG5623 IC OPTO ISOLATOR CT-27D32F/UF
IC802 PC123FY2 IC OPTO ISOLATORCT-27D32F/UF
IC803 STR58041A IC POWER SUPPLY B+
IC1801 M65617SP
IC PIP CONTROL
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
IC2101 AN5170K
IC VIF,SIF,AFC, DET
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
IC2201 AN5849S-E1V IC MTS
IC2301 AN5277 IC AUDIO AMP CT-27D32F/UF
IC2302 AN5272 IC AUDIO AMP
IC2351 CXA2021S IC S-AGC
IC3001 M52790SP IC A/V SWITCH
IC6501 MN82840 IC 3 LINE COMB FILTER
IC6502 PST9142NR IC COMB FILTER RESET
COILS
L001 EXCELSA26T FERRITE BEAD
L002 TLTABT2R2K COIL, PEAKING 2.2UH
L003 TLTABT2R2K COIL, PEAKING 2.2UH
L004 TLTABT2R2K COIL, PEAKING 2.2UH
L005 ELESN330KA COIL, PEAKING 33UH
L006 EXCELSA24T FERRITE BEAD
L007 ELESN180JA COIL, PEAKING 18UH
L008 TLTABT470K COIL, PEAKING 47UH
REF
NO.
PART NO. DESCRIPTION
L010 TLTABT2R2K COIL, PEAKING 2.2UH
L011 TLTABT2R2K COIL, PEAKING 2.2UH
L012 TLTABT2R2K COIL, PEAKING 2.2UH
L013 TLTABT2R2K COIL, PEAKING 2.2UH
L106 EXCELSA26T FERRITE BEAD
L108 EXCELSA26T FERRITE BEAD
L109 EXCELSA26T FERRITE BEAD
L110 EXCELSA39V FERRITE BEAD
L218 EXCELSA26T FERRITE BEAD
L319 TLTABT101K COIL, PEAKING
L351 TLTABT101K
COIL, PEAKING
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
L355 ELESN270KA
COIL, PEAKING 27UH
CT-36D12DF/DUF CT-36D32F/UF
L356 ELESN390KA
COIL, PEAKING 39UH
CT-36D12DF/DUF CT-36D32F/UF
L357 ELESN270KA
COIL, PEAKING 27UH
CT-36D12DF/DUF CT-36D32F/UF
L358 ELESN101JA
COIL, PEAKING 100UH
CT-36D12DF/DUF CT-36D32F/UF
L359 ELESN101JA
COIL, PEAKING 100UH
CT-36D12DF/DUF CT-36D32F/UF
L360 ELESN101JA
COIL, PEAKING 100UH
CT-36D12DF/DUF CT-36D32F/UF
L430 EXCELSA39V FERRITE BEAD
L501 ELESN3R3KA COIL, PEAKING 3.3UH
L518 ELESN120JA COIL, PEAKING 12UH
L541 EXCELDR35V FERRITE BEAD
L542 EXCELSA39V
FERRITE BEAD
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF CT-32D12DF/DUF
L543 EXCELSA26T
FERRITE BEAD
CT-3207DF/DUF CT-32D32F/UF
SP-3235F/UF
L551 ELH5L7101
COIL, HORIZ. LINEARITY
CT-36D12DF/DUF CT-36D32F/UF
L551 ELH5L7103
COIL CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
L551 ELH5L7115
COIL, HORIZONTAL LINEARIT
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
L554 EXCELSA24T FERRITE BEAD
L555 EXCELSA24T FERRITE BEAD
L556 EXCELSA24T FERRITE BEAD
L751 ELC18B301L
COIL, CHOKE
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
L752 EXCELDR35V
FERRITE BEAD
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
L801 ELF20N020A COIL, 2UH
REF
NO.
PART NO. DESCRIPTION
