Parts List
REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
042-02
PARTS LIST
Q953 2SC1685QRSTA
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q954 2SA564AQRSTA
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q955 2SB1569AF51E
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q956 2SD2400AF51E
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q961 2SC1685QRSTA
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q962 2SA564AQRSTA
TRANSISTOR
CT-36D12DF/DUF CT-36D32F/UF
Q1801 2SD601ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32FUF SP-3235F/UF
Q1802 2SD601ARTX
TRANSISTOR
CT-2707DF/DUFCT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q1803 2SD601ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q1804 2SB709ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q1805 2SB709ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q2101 2SD601ARTX
TRANSISTOR
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
Q2302 2SB709ARTX TRANSISTOR
Q2303 2SD601ARTX TRANSISTOR
Q2342 2SB709ARTX TRANSISTOR
Q2343 2SD601ARTX TRANSISTOR
Q2344 2SD601ARTX TRANSISTOR
Q2409 2SD601ARTX TRANSISTOR
Q2410 2SD601ARTX TRANSISTOR
Q4309 2SB709ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q4310 2SD601ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q4311 2SB709ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q4312 2SD601ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
Q4313 2SD601ARTX
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q4315 2SC1384QR
TRANSISTOR
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
Q6501 2SD601ARTX TRANSISTOR
Q6502 2SD601ARTX TRANSISTOR
Q6504 2SD601ARTX TRANSISTOR
Q6505 2SD601ARTX TRANSISTOR
Q6506 2SD601ARTX TRANSISTOR
Q6509 2SD601ARTX TRANSISTOR
Q6510 2SB709ARTX TRANSISTOR
Q6514 2SB709ARTX TRANSISTOR
Q6516 2SB709ARTX TRANSISTOR
Q6517 2SD601ARTX TRANSISTOR
Q6519 2SD601ARTX TRANSISTOR
RELAYS
RL801 TSEH8007 RELAY
RESISTORS
R001 ERJ6GEYJ471V RES,M 470-J-1/10W
R002 ERJ6GEYJ182V RES,M 1.8K-J-1/10W
R003 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R004 ERDS1TJ122T RES,C 1.2K-J-1/2W
R005 ERDS2TJ101T RES,C 100-J-1/4W
R006 ERDS1TJ560T RES,C 56-J-1/2W
R007 ERJ6GEYJ103V RES,M 10K-J-1/10W
R008 ERJ6GEYJ103V RES,M 10K-J-1/10W
R009 ERJ6GEYJ221V RES,M 220-J-1/10W
R010 ERJ6GEYJ103V RES,M 10K-J-1/10W
R012 ERJ6GEYJ102V RES,M 1K-J-1/10W
R013 ERJ6GEYJ223V RES,M 22K-J-1/10W
R014 ERJ6GEYJ392V RES,M 3.9K-J-1/10W
R015 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R016 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R017 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R020 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R021 ERJ6GEYJ101V RES,M 100-J-1/10W
R022 ERJ6GEYJ101V RES,M 100-J-1/10W
R023 ERJ6GEYJ102V RES,M 1K-J-1/10W
R024 ERJ6GEYJ221V RES,M 220-J-1/10W
R025 ERJ6GEYJ223V RES,M 22K-J-1/10W
R026 ERJ6GEYJ103V RES,M 10K-J-1/10W SP-3235F/UF
R026 ERJ6GEYJ183V
RES,M 18K-J-1/10W
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF
R026 ERJ6GEYJ223V
RES,M 22K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
R027 ERJ6GEYJ103V
RES,M 10K-J-1/10W
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-32D12DF/DUF
CT-36D12DF/DUF
REF
NO.
PART NO. DESCRIPTION
