Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 29.3 39.4
Rated Output W 15 15
Fan Speed Low rpm 800 —
Medium rpm 940 —
High rpm 1,160 795
SuperHigh rpm 1,250 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 687 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(330)
Refrigerant (R410A) g(oz) — 970 (34.2)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — 615
Flow Rate l/min — 14.4
Inner Diameter mm — 1.6
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 35 µF, 400 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 1.0 µF, 430 VAC
• Specifications are subject to change without notice for further improvement.
7
