16 Replacement Parts List
<Model: CS-V7BKPG / CS-V9BKPG / CS-V12BKPG>
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-V7BKPG CS-V9BKPG CS-V12BKPG REMARKS
1 CHASSY COMPLETE 1 CWD50C1231 ← ←
2 FAN MOTOR 1 CWA921060 ← ← 0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1012 ← ←
4 BEARING ASS’Y 1 CWH64K007 ← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304 ← ←
6 EVAPORATOR 1 CWB30C1143 ← CWB30C1124
7 FLARE NUT 1 CWH6002140(1/4”) ← ←
8 FLARE NUT 1 CWT25005 (3/8”) ← CWT25007 (1/2”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142 ← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2101 ← ←
11 VERTICAL VANE 12 CWE241068 ← ←
12 CONNECTING BAR 2 CWE261024 ← ←
13 AIR SWING MOTOR 1 CWA98259 ← ← 0
14 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977 ← ←
15 CAP - DRAIN TRAY 1 CWH52C1001 ← ←
16 HORIZONTAL VANE 1 CWE241070 ← ←
17 PARTICULAR PIECE 1 CWD932162 ← ←
18 CONTROL BOARD 1 CWH102103 ← ←
19 TERMINAL BOARD COMPLETE 1 CWA28C2082 ← ← 0
20 ELECTRONIC CONTROLLER - MAIN 1 CWA742779 CWA742780 CWA742781 0
21 LEAD WIRE - FAN MOTOR 1 CWA67C3729 ← ←
22 ELECTRONIC CONTROLLER - RECEIVER 1 CWA73C1124 ← ← 0
23 SENSOR COMPLETE 1 CWA50C608 ← ← 0
24 CONTROL BOARD FRONT COVER 1 CWH131090 ← ←
25 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1063 ← ← 0
26 LEAD WIRE - INDICATOR 1 CWA67C3724 ← ←
27 INDICATOR HOLDER 1 CWD932163 ← ←
28 CONTROL BOARD TOP COVER 1 CWH131091 ← ←
29 REMOTE CONTROL COMPLETE 1 CWA75C2161 ← ← 0
30 FRONT GRILLE COMPLETE 1 CWE11C2329 ← ←
31 INTAKE GRILLE 1 CWE221036 ← ←
32 CONTROL PANEL 1 CWE312114 ← ←
33 DECORATION BASE (R) 1 CWE351067 ← ←
34 DECORATION BASE (L) 1 CWE351068 ← ←
35 GRILLE DOOR 1 CWE141033 ← ←
36 AIR FILTER 2 CWD001047 ← ←
37 SCREW - FRONT GRILLE 2 XTN4+16C ← ←
38 CAP - FRONT GRILLE 2 CWH521062 ← ←
39 DRAIN HOSE 1 CWH85287 ← ←
40 INSTALLATION PLATE 1 CWH36K1006 ← ←
41 ANTI-VIBRATION BUSHING 1 - - CWH501023
42 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ← ←
43 AIR PURIFYING FILTER 1 CWMD00C0001 ← ← 0
44 SOLAR DEODORIZING FILTER 1 CWMD00C0002 ← ← 0
45 PIPE SENSOR HOLDER 1 CWH32143 ← ←
(Note)
• All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
73
CS-V9BKPG CU-2V14BKP5G / CS-V9BKPG CU-2V18BKP5G / CS-V9BKP G CU-3V20BKP5G / CS-V7BKP G CU-2V19BKP5G / CS-V12BKPG
