Note:
Refrigerant (R-22) g (oz) (1)
(3)
(4)
(7)
— 815 (28.7)
(2)
(5)
(6)
— 890 (31.4)
Thermostat Electronic Control —
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 720
Flow Rate l/min — 11.0
Inner Diameter mm — 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC (1)
(3)
(4)
(7)
— 30 µF, 370VAC
(2)
(5)
(6)
— 15 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-C9BKP/CU-C9BKP5 (Europe).
• (2) — CS-C9BKP-1/CU-C9BKP6-1 (Panama).
• (3) — CS-C9BKP-2/CU-C9BKP5-2 (Oceania).
• (4) — CS-C9BKP-3/CU-C9BKP5-3 (Argentina).
• (5) — CS-C9BKP-4/CU-C9BKP6-4 (USA).
• (6) — CS-C9BKP-5/CU-C9BKP6-5 (Canada).
• (7) — CS-C9BKP-6/CU-C9BKP5-6 (Turkey).
11
CS-C7BKP CU-C7BKP5 / CS-C7BKP CU-C7BKP6 / CS-C9BKP CU-C9BKP5 / CS-C9BKP CU-C9BKP6 / CS-C12BKP CU-C12BKP5 / CS-C12BKP CU-C12BKP6
