Panasonic CU-C7BKP6 - 16 Replacement Parts List

16 Replacement Parts List
<Model: CS-C7BK / CS-C9BK / CS-C12BK>
REF. NO. PART NAME & DESCRIPTION QTY. CS-C7BK CS-C9BK CS-C12BK REMARKS
1 CHASSY COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWD50C1177
-
CWD50C1177
-
-
-
-
←
CWD50C1177
←
CWD50C1177
CWD50C1208
CWD50C1208
CWD50C1177
←
←
←
←
←
←
←
2 FAN MOTOR 1 CWA921060 ← ← 0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1012 ← ←
4 BEARING ASS’Y 1 CWH64K007 ← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304 ← ←
6 EVAPORATOR 1 CWB30C1143 ← CWB30C1124
7 FLARE NUT 1 CWH6002140(1/4”) ← ←
8 FLARE NUT 1 CWT25005 (3/8”) ← CWT25007 (1/2”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142 ← ←
10 DISCHARGE GRILLE COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWE20C2101
-
CWE20C2101
-
-
-
-
←
CWE20C2101
←
CWE20C2101
CWE20C2126
CWE20C2126
CWE20C2101
←
←
←
←
←
←
←
11 VERTICAL VANE 12 CWE241068 ← ←
12 CONNECTING BAR 2 CWE261024 ← ←
13 AIR SWING MOTOR 1 CWA98259 ← ← 0
14 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977 ← ←
15 CAP - DRAIN TRAY 1 CWH52C1001 ← ←
16 HORIZONTAL VANE 1 CWE241070 ← ←
17 PARTICULAR PIECE 1 CWD932162 ← ←
18 CONTROL BOARD 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWH102103
-
CWH102103A
-
-
-
-
←
CWH102103
←
CWH102103
CWH102103B
CWH102103B
CWH102103
←
←
←
←
←
←
←
19 TERMINAL BOARD COMPLETE 1 CWA28C2073 ← CWA28C2075 0
20 POWER SUPPLY CORD 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWA20C2159
-
CWA20C2159
-
-
-
-
←
CWA20C2159
←
CWA20C2195
CWA20C2209
CWA20C2209
CWA20C2159
←
←
←
←
←
←
←
21 ELECTRONIC CONTROLLER - MAIN 1 CWA742636 CWA742635 CWA742474 0
22 LEAD WIRE - FAN MOTOR 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWA67C3729
-
CWA67C3729
-
-
-
-
←
CWA67C3729
←
CWA67C3729
CWA67C3961
CWA67C3961
CWA67C3729
←
←
←
←
←
←
←
23 ELECTRONIC CONTROLLER - RECEIVER 1 CWA73C1124 ← ← 0
24 SENSOR COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWA50C608
-
CWA50C608
-
-
-
-
←
CWA50C608
←
CWA50C608
CWA50C2086
CWA50C2086
CWA50C608
←
←
←
←
←
←
←
0
25 CONTROL BOARD FRONT COVER 1 CWH131090 ← ←
26 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1042 ← ← 0
27 LEAD WIRE - INDICATOR 1 CWA67C3637 ← ←
28 INDICATOR HOLDER 1 CWD932163 ← ←
29 CONTROL BOARD TOP COVER 1 CWH131091 ← ←
30 REMOTE CONTROL COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWA75C2162
-
CWA75C2162
-
-
-
-
←
CWA75C2162
←
CWA75C2162
CWA75C2221
CWA75C2162
CWA75C2162
←
←
←
←
←
←
←
0
31 FRONT GRILLE COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWE11C2329
-
CWE11C2329
-
-
-
-
←
CWE11C2329
←
CWE11C2329
CWE11C2470
CWE11C2470
CWE11C2329
←
←
←
←
←
←
←
69
CS-C7BKP CU-C7BKP5 / CS-C7BKP CU-C7BKP6 / CS-C9BKP CU-C9BKP5 / CS-C9BKP CU-C9BKP6 / CS-C12BKP CU-C12BKP5 / CS-C12BKP CU-C12BKP6
