REF. NO. PART NAME & DESCRIPTION QTY. CS-C7BK CS-C9BK CS-C12BK REMARKS
32 INTAKE GRILLE 1 CWE221036 ← ←
33 CONTROL PANEL 1 CWE312114 ← ←
34 DECORATION BASE (R) 1 CWE351067 ← ←
35 DECORATION BASE (L) 1 CWE351068 ← ←
36 GRILLE DOOR 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWE141033
-
CWE141033
-
-
-
-
←
CWE141033
←
CWE141033
CWE141047
CWE141047
CWE141033
←
←
←
←
←
←
←
37 AIR FILTER 2 CWD001047 ← ←
38 SCREW - FRONT GRILLE 2 XTN4+16C ← ←
39 CAP - FRONT GRILLE 2 CWH521062 ← ←
40 DRAIN HOSE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
CWH85287
-
CWH85287
-
-
-
-
←
CWH85287
←
CWH85287
CWH851041
CWH851041
CWH85287
←
←
←
←
←
←
←
41 INSTALLATION PLATE 1 CWH36K1006 ← ←
42 ANTI-VIBRATION BUSHING 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
CWH501023
-
CWH501023
CWH501023
CWH501023
CWH501023
CWH501023
43 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ← ←
44 AIR PURIFYING FILTER 1 CWMD00C0001 ← ← 0
45 SOLAR DEODORIZING FILTER 1 CWMD00C0002 ← ← 0
46 WIRE NET 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
-
-
-
-
-
-
-
-
-
-
-
CWD041025A
CWD041025A
-
-
-
-
-
←
←
-
47 CONTROL BOARD COVER COMPLETE 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
-
-
-
-
-
-
-
-
-
-
-
CWH13C1053
CWH13C1053
-
-
-
-
-
←
←
-
48 CONTROL BOARD COVER 1 (1)
(2)
(3)
(4)
(5)
(6)
(7)
-
-
-
-
-
-
-
-
-
-
-
CWH131113
CWH131113
-
-
-
-
-
←
←
-
(Note)
• All parts are supplied from MACC, Malaysia (Vendor Code: 086).
• “O” marked parts are recommended to be kept in stock.
• (1) — CS-C7BKP, CS-C9BKP, CS-C12BKP (Europe).
• (2) — CS-C9BKP-1, CS-C12BKP-1 (Panama).
• (3) — CS-C7BKP-2, CS-C9BKP-2, CS-C12BKP-2 (Oceania).
• (4) — CS-C9BKP-3, CS-C12BKP-3 (Argentina).
• (5) — CS-C9BKP-4, CS-C12BKP-4 (USA).
• (6) — CS-C9BKP-5, CS-C12BKP-5 (Canada).
• (7) — CS-C9BKP-6, CS-C12BKP-6 (Turkey).
70
CS-C7BKP CU-C7BKP5 / CS-C7BKP CU-C7BKP6 / CS-C9BKP CU-C9BKP5 / CS-C9BKP CU-C9BKP6 / CS-C12BKP CU-C12BKP5 / CS-C12BKP CU-C12BKP6
