Note:
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 605
Flow Rate l/min — 15.7
Inner Diameter mm — 1.7
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-C12BKP/CU-C12BKP5 (Europe).
• (2) — CS-C12BKP-1/CU-C12BKP6-1 (Panama).
• (3) — CS-C12BKP-2/CU-C12BKP5-2 (Oceania).
• (4) — CS-C12BKP-3/CU-C12BKP5-3 (Argentina).
• (5) — CS-C12BKP-4/CU-C12BKP6-4 (USA).
• (6) — CS-C12BKP-5/CU-C12BKP6-5 (Canada).
• (7) — CS-C12BKP-6/CU-C12BKP5-6 (Turkey).
