Panasonic CU-MC180KE - Replacement Parts List (CU-MC180 KE)

– 50 –
MAC9702008C2
CS-MC90KE
(Note) ● All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
● The above parts are kept for seven years in accordance with MEI service policy. However, longer lead time will
be taken in supplying the non-numbered parts.
● t marked parts are recommended to be kept in stock.
Replacement Parts List
DESCRIPTION & NAME
BASE ASS'Y
AIR GUIDER FOR P.F.
SOUND PROOF COVER
FAN MOTOR BRACKET
CONDENSER
FAN MOTOR
PROPELLER FAN
COMPRESSOR
3-WAY VALVE (LIQUID SIDE)
3-WAY VALVE (GAS SIDE)
COUPLING BRACKET
CAPILLARY TUBE
CONTROL BOARD
CAPACITOR – COMPRESSOR
CAPACITOR – FAN MOTOR
ELECTRO MAGNETIC RELAY
RESISTOR
TERMINAL BOARD
OVERLOAD PROTECTOR
HOLDER – OVERLOAD PROTECTOR
TERMINAL COVER – COMPRESSOR
CABINET TOP PLATE
CONTROL BOARD COVER – CABINET
FRONT PLATE
CABINET SIDE PLATE
FAN GUARD
HANDLE
SOUND – PROOF MATERIAL
MOUNT RUBBER – COMPRESSOR
STRAINER
OPERATING INSTRUCTION
INSTALLATION INSTRUCTION
NUT COMPRESSOR
HOLDER CAPACITOR
NUT TERMINAL COVER
Q’TY
1
1
1
1
1
1
1
2
2
2
1
2
1
2
1
2
2
1
2
2
2
1
1
1
1
1
1
2
6
2
1
1
6
2
2
CU-MC180KE
CWD50K572A
CWD31094A
CWH15071
CWD54179
CWB32487
CWA95269
CWH00023
2PS134D2AA01
CWB01383
CWB01384
CWH35083A
CWB15199
CWH10775
CWA31646
(370VAC, 25µF)
CWA31289
(450VAC, 3µF)
CWA00010
CWA46C001
CWA28059
CWA12336
CWH7041200
CWH7070204
CWE03C026
CWH13244
CWE06C110A
CWE04069A
CWD04183
CWE16000E
CWG30267
CWH50049
CWB11002
CWF561246
CWF61532
CWH56000
CWH30078
CWH7080300
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
<Model: CU-MC180KE>
REMARKS
t
t
t
t
t
t
t
t
t
t
