CS-MC90KE
Electronic Parts List
<Model: CS-MC90KE>
CWA74813 • ELECTRONIC CONTROLLER (MAIN)
DESCRIPTION & NAME
SOUND GENERATOR
SH CAPACITOR
DIODE
DIODE
FUSE
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
V–COIL
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
ELECTRO MAGNETIC RELAY
ELECTRO MAGNETIC RELAY
TYRISTOR
SLIDE SWITCH
PUSH SWITCH
RESONATOR
DIODE
DIODE
PART NO.
A48004
A31496
A54RA15–01V3
A54CS1VB20E
XBA2C31TR0
A52D0001W013
A52C040
A52MPA2003C
A52BR9011B
A52C094
A43036
A55DTC143XST
A55DTC114EST
A55C1740STPR
A55C1741ASTR
A00160
A00106
A56W2DEH1–5
A04042
A01059
A45ST8.0MTWT
A54D7.5EL1TB
A54C036
SYMBOL
BZ1
C–FM
D2
DB1
FUSE
IC1
IC2
IC3
IC4
IC5
L1, L2
Q3
Q2
Q4, Q5
Q1
RY–H, RY–M
RY–C
SSR
SW3
SW1, SW2
X1
ZD1
ZNR1, ZNR2
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
