Panasonic CU-PE12DKE - Replacement Parts List

No. DESCRIPTION&NAME
Q'TY CS-PE9DKE CS-PE12DKE RE
1
CHASSIS COMPLETE
1 CWD50C1427 CWD50C1427
2
FAN MOTOR
1 ARW41W8P30AC ARW41W8P30AC
3
CROSS FLOW FAN COMPLETE
1 CWH02C1036 CWH02C1036
4
EVAPORATOR
1 CWB30C1558 CWB30C1558
6
FIXING BOARD
1 CWD661043 CWD661043
7
DISCHARGE GRILLE COMPLETE
1 CWE20C2436 CWE20C2409
8
AIR SWING MOTOR
1 CWA981091 CWA981091
9
HORIZONTAL VANE(LEFT)
1 CWE24C1104 CWE24C1104
10
HORIZONTAL VANE(RIGHT)
1 CWE24C1105 CWE24C1105
11
VERTICAL VANE
1 CWE24C1100 CWE24C1100
12
C-BOX
1 CWH14C4628A CWH14C4628B
13
CONTROL BOARD
1 CWH102265 CWH102265
14 HOLDER 1 CWD932493 CWD932493
15 TERMINAL BOARD COMPLETE 1 CWA28C2234 CWA28C2234
16
POWER SUPPLY CORD COMPLETE
1 CWA20C2443 CW
A20C2443
1
7
ELECTRONIC CONTROLLER 1 CWA743824A CWA743824B
18 SENSOR 1 L2GZ00000003 L2GZ00000003
19
INDICATOR HOLDER-FRONT
1 CWD932491 CWD932491
20
INDICATOR HOLDER-BACK
1 CWD932492 CWD932492
21
INDICATOR PCB
1 CWA743836 CWA743836
23
CONTROL BOARD FRONT COVER
1 CWH131235 CWH131235
24
CONTROL BOARD TOP COVER
1 CWH131237 CWH131237
25
REMOTE CONTROL
1 CWA75C2683 CWA75C2683
26
FRONT GRILLE COMPLETE
1 CWE11C3214 CWE11C3214
27
FRONT GRILLE
1 CWE22K1259 CWE22K1259
28
GRILLE DOOR
1
CWE141073 CWE141073
29
AIR FILTER
2 CWD001144 CWD001144
30
SCREW-FRONT GRILLE
2 XTT4+16CFJ XTT4+16CFJ
31
CAP-FRONT GRILLE
2 CWH521109 CWH521109
32
DRAIN HOSE
1 CWH851063 CWH851063
33
OPERATING INSTRUCTIONS
1 CWF564703 CWF564703
34
INSTALLATION INSTRUCTIONS
1 CWF612795 CWF612795
35
INST
ALLAT
ION INSTRUCTIONS
1 CWF612796 CWF612796
36
INSTALLATION INSTRUCTIONS
1 CWF612797 CWF612797
37
INSTALLATION PLATE
1 CWH361067 CWH361067
69
15 Replacement Parts List
Note:
1.All parts are supplied from GMAC, P.R. China.
2."*" marked parts are recommended to be kept in stock.
CS-PE9DKE
CS-PE12DKE
CS-PE9DKE / CU-PE9DKE / CS-PE12DKE / CU-PE12DKE
