Panasonic CU-V7CKP5 - Replacement Parts List

16 Replacement Parts List
<Model: CS-V7CKP / CS-V9CKP / CS-V12CKP>
REF. NO. PART NAME & DESCRIPTION QTY. CS-V7CKP CS-V9CKP CS-V12CKP REMARKS
1 CHASSY COMPLETE 1 CWD50C1246
← ←
2 FAN MOTOR 1 CWA921060
← ←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1012
← ←
4 BEARING ASS’Y 1 CWH64K007
← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
6 EVAPORATOR 1 CWB30C1262
←
CWB30C1245
7 FLARE NUT 1 CWH6002140(1/4”)
← ←
8 FLARE NUT 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2101
← ←
11 VERTICAL VANE 12 CWE241068
← ←
12 CONNECTING BAR 2 CWE261024
← ←
13 AIR SWING MOTOR 1 CWA98259
← ←
0
14 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
← ←
15 CAP - DRAIN TRAY 1 CWH52C1001
← ←
16 HORIZONTAL VANE 1 CWE241070
← ←
17 PARTICULAR PIECE 1 CWD932162
← ←
18 CONTROL BOARD 1 CWH102103
← ←
19 TERMINAL BOARD COMPLETE 1 CWA28C2151
←
CWA28C2152 0
20 POWER SUPPLY CORD 1 CWA20C2159
← ←
21 ELECTRONIC CONTROLLER - MAIN 1 CWA742978 CWA742977 CWA742874 0
22 LEAD WIRE - FAN MOTOR 1 CWA67C3729
← ←
23 ELECTRONIC CONTROLLER - RECEIVER 1 CWA73C1124
← ←
0
24 SENSOR COMPLETE 1 CWA50C2122
← ←
0
25 CONTROL BOARD FRONT COVER 1 CWH131090
← ←
26 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1064
← ←
0
27 LEAD WIRE - INDICATOR 1 CWA67C3637
← ←
28 INDICATOR HOLDER 1 CWD932163
← ←
29 CONTROL BOARD TOP COVER 1 CWH131091
← ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2292
← ←
0
31 FRONT GRILLE COMPLETE 1 CWE11C2756
← ←
32 INTAKE GRILLE 1 CWE22C1081
← ←
33 CONTROL PANEL 1 CWE312274
← ←
34 DECORATION BASE (R) 1 CWE351067
← ←
35 DECORATION BASE (L) 1 CWE351068
← ←
36 GRILLE DOOR 1 CWE141033
← ←
37 AIR FILTER 2 CWD001047
← ←
38 SCREW - FRONT GRILLE 2 XTN4+16C
← ←
39 CAP - FRONT GRILLE 2 CWH521062
← ←
40 DRAIN HOSE 1 CWH85285
← ←
41 INSTALLATION PLATE 1 CWH36K1006
← ←
42 ANTI-VIBRATION BUSHING 1 - - -
43 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
← ←
44 AIR PURIFYING FILTER 1 CWMD00C0001
← ←
0
45 TRIPLE DEODORIZING FILTER 1 CWMD00C0004
← ←
0
46 FULCRUM 1 CWH621013
← ←
47 ELECTRONIC CONTROLLER - IONIZER 1 CWA743099
← ←
48 CASING - IONIZER 1 CWD932228
← ←
49 ION GENERATOR 1 CWH94C0001
← ←
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
66
CS-V7CKP CU-V7CKP5 / CS-V9CKP CU-V9CKP5 / CS-V12CKP CU-V12CKP5
