Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — FVC68D (330)
Refrigerant (R-410A) g (oz) — 950 (33.5)
Thermostat Electronic Control —
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 803
Flow Rate l/min — 8.5
Inner Diameter mm — 1.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
•
Specifications are subject to change without notice for further improvement.
9
CS-V7CKP CU-V7CKP5 / CS-V9CKP CU-V9CKP5 / CS-V12CKP CU-V12CKP5
