13
(EN)
Flap Setting for Each Air Outlet
Lock indiv. ß ap
When setting the ß ap for each air outlet individually according to the
room condition
• Even if the ß ap setting of all indoor units (P.9) or each indoor unit (P. 12) is
changed, the ß ap directions set here are not changed.
1
Display the menu screen.
To return to the previous screen
Press .
To return to the top screen
Press 2 times.
2
Select [Lock indiv. ß ap].
Ÿ ź ĺ
3
Select the indoor unit to set.
Ÿ ź ĺ Ź
e.g. 1-1 ĺ 1-2 to 1-8
4
Select the air outlet.
Ÿ ź ĺ Ź
• The air outlet No. changes according to
the installation direction. Check by actual
operation.
1
2
3
4
5
Select the ß ap direction.
Ÿ ź ĺ
(Press 2 times to Þ nish.)
• Although is also displayed in
Cool and Dry mode, the actual direction
is
.
* For types other than the 4-way cassette
type, the following display appears and
this function cannot be used.
Swing
Unlock
