Panasonic DMC-FT2 - Camera Components; Names of the Components; Cursor buttons functionality

17
(ENG) VQT2M46
Names of the Components
1Flash
2 Self-timer indicator/
AF assist lamp/LED light
3 Lens
4 LCD monitor
5 Motion picture button
6 [MENU/SET] button
7 [DISPLAY] button
8 [Q.MENU]/Delete button
9 Playback button
10 Mode dial
11 Cursor buttons
A: 3/Exposure compensation/Auto
bracket/White balance fine
adjustment
B: 4/Macro mode/
AF Tracking
C: 2/Self-timer button
D: 1/Flash setting button
In these operating instructions, the cursor buttons are described as
shown in the figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
21 3
4511
786
9
10
DMC-FT2&TS2GN-VQT2M46_eng.book 17 ページ ２０１０年２月９日 火曜日 午前８時４６分
