15
[Only for "EG, EB and EC" models : (VEP56106B is used as a Main P.C.B.)]
When MAIN P.C.B. and/or Flash-ROM (IC6007) has just been replaced, only 4 model suffix are displayed as follows.
[CASE 2. Other than "After replacing MAIN P.C.B. and/or Flash-ROM (IC6007)"]
• Step 5. Choose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION”)
[Caution: After replacing MAIN P.C.B. and/or Flash-ROM (IC6007)]
The model suffix can been chosen, JUST ONE TIME.
Once one of the model suffix have been chosen, the model suffix lists will not be displayed, thus, it can be changed.
Therefore, select the area carefully.
Select the area with pressing “[ UP ] / [ DOWN ] of Cursor buttons”.
• Step 6. Set the model suffix in “INITIAL SETTINGS”:
- Press the “[ RIGHT ] of Cursor buttons”.
- The only set area is displayed, and then press the “[ RIGHT ] of Cursor buttons” after confirmation.
(The unit is powered off automatically.)
• Step 7. CONFIRMATION:
Confirm the display of “PLEASE SET THE CLOCK” in concerned language when the unit is turned on again.
When the unit is connected to PC with USB cable, it is detected as removable media.
1) As for your reference, major default setting condition is as shown in the following table.
• Default setting (After “INITIAL SETTINGS”)
MODEL VIDEO OUTPUT LANGUAGE DATE REMARKS
a) DMC-G2 (Japan domestic model) NTSC Japanese Year/Month/Date
b) DMC-G2PP NTSC English Month/Date/Year
c) DMC-G2EG PAL English Date/Month/Year
d) DMC-G2GC PAL English Date/Month/Year
e) DMC-G2GK PAL Chinese (simplified) Year/Month/Date
f) DMC-G2EB PAL English Date/Month/Year
g) DMC-G2GN PAL English Date/Month/Year
h) DMC-G2EC PAL English Date/Month/Year
i) DMC-G2GH PAL English Date/Month/Year
j) DMC-G2GD NTSC Korean Year/Month/Date
k) DMC-G2GT NTSC Chinese (traditional) Year/Month/Date
