5.2. Service Position
This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.
Table S1 Extension Cable List
No. Parts No. Connection From
1 VFK1175 FP9001(MAIN) - REAR OPERATION UNIT 16PIN 0.5FFC
2 VFK1364 FP9002(MAIN) - MOUNT BOX UNIT(SHUTTER) 14PIN 0.5FFC
3 VFK1284 FP9003(MAIN) - TOP CASE (R) UNIT(HOT SHOE FPC) 24PIN 0.5FFC
4 RFKZ0477 FP9004(MAIN) - LVF UNIT 45PIN 0.3FFC
5 VFK1175 FP9007(MAIN) - TOP OPERATION (L) UNIT 16PIN 0.5FFC
6 RFKZ0393 FP9009(MAIN) - FP7350(REMOTE) 15PIN to 10PIN 0.3FFC
7 VFK2024 FP9010(MAIN) - FP1001(POW FLASH) 51PIN 0.3FFC
8 VFK1480 FP9011(MAIN) - OPTICAL SENSOR UNIT 6PIN 0.5FFC
9 VFK1951 FP9090(MAIN) - LCD UNIT 39PIN 0.3FFC
10 RFKZ0477 FP3901(MAIN) - MOUNT BOX UNIT(SENSOR) 45PIN 0.3FFC
11 RFKZ0477 FP3902(MAIN) - MOUNT BOX UNIT(SENSOR) 45PIN 0.3FFC
12 RFKZ0477 FP3903(MAIN) - MOUNT BOX UNIT(SENSOR) 45PIN 0.3FFC
13 RFKZ0477 FP3904(MAIN) - MOUNT BOX UNIT(SENSOR) 45PIN 0.3FFC
14 RFKZ0564 FP9008(MAIN) - MOUNT BOX UNIT(LENS I/F) 23PIN 0.3FFC
15 RFKZ0359 P9002(MAIN) - MOUNT BOX UNIT(SSWF) 2PIN CONNECTOR
16 RFKZ0359 P8503(POW FLASH) - FLASH UNIT 2PIN CONNECTOR
17 VFK1576DC202 P8504(POW FLASH) - FLASH UNIT 2PIN CONNECTOR
18 VFK1576DC202 P9005(MAIN) - HINGE SW P.C.B. 2PIN CONNECTOR
To Next Page
