S2. Voltage Chart
S2.1. Main P.C.B.
Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
REF No. PIN No. POWER ON
IC2001 1 0
IC2001 2 3.1
IC2001 3 0
IC2001 4 0
IC2001 5 0
IC2001 6 0
IC2001 7 0
IC2001 8 0
IC2704 1 -
IC2704 2 4.8
IC2704 3 0
IC2704 4 0
IC2704 5 3
IC3011 1 3.2
IC3011 2 0
IC3011 3 3
IC3011 4 3.5
IC3021 1 3.2
IC3021 2 0
IC3021 3 3
IC3021 4 3.5
IC3022 1 1.7
IC3022 2 0
IC3022 3 3
IC3022 4 1.8
IC3031 1 1
IC3031 2 0
IC3031 3 3.2
IC3031 4 1.8
IC3032 1 1
IC3032 2 0
IC3032 3 3.2
IC3032 4 1.8
IC3041 1 4.2
IC3041 2 0
IC3041 3 3
IC3041 4 4.8
IC3051 1 4.2
IC3051 2 0
IC3051 3 3
IC3051 4 4.8
IC3061 1 0.6
IC3061 2 0
IC3061 3 4.2
IC4003 1 3
IC4003 2 0
IC4003 3 0
IC4003 4 4.8
IC6002 1 3
IC6002 2 0
IC6002 3 0
IC6002 4 3
IC6002 5 0
IC6002 6 0
IC6004 1 3
IC6004 2 0
IC6004 3 2.7
IC6004 4 2.7
IC6004 5 3
IC6004 6 0
IC6004 7 2.7
IC6004 8 1.1
IC6004 9 3
IC6004 10 0
IC6004 11 3
IC6004 12 0
REF No. PIN No. POWER ON
IC6004 13 0
IC6004 14 0
IC6004 15 0
IC6004 16 3
IC6004 17 3
IC6004 18 0
IC6004 19 0
IC6004 20 3
IC6005 1 1.8
IC6005 2 1.8
IC6005 3 1.8
IC6005 4 0
IC6005 5 0
IC6005 6 3.4
IC6005 7 3.4
IC6005 8 2.8
IC6006 1 3
IC6006 2 3
IC6006 3 1.8
IC6006 4 1.5
IC6006 5 0
IC6006 6 3
IC6006 7 2.1
IC6006 8 1.3
IC6006 9 0
IC6006 10 0
IC6006 11 3
IC6006 12 0
IC6006 13 1.8
IC6006 14 1.3
IC6006 15 0
IC6006 16 0
IC6006 17 0.6
IC6006 18 1.2
IC6006 19 0
IC6006 20 3
IC6008 1 3
IC6008 2 3
IC6008 3 2.5
IC6008 4 2.5
IC6008 5 3
IC6008 6 3
IC6008 7 2.6
IC6008 8 2.6
IC6008 9 0
IC6008 10 0
IC6008 11 3
IC6008 12 2.8
IC6008 13 3
IC6008 14 3
IC6008 15 3
IC6008 16 3
IC6008 17 3
IC6008 18 3
IC6008 19 3
IC6008 20 3
IC6009 1 3
IC6009 2 0
IC6009 3 2.5
IC6009 4 2.5
IC6009 5 0
IC6009 6 3
IC6009 7 2.6
IC6009 8 2.6
IC6009 9 0
IC6009 10 0
REF No. PIN No. POWER ON
IC6009 11 3
IC6009 12 0
IC6009 13 2.5
IC6009 14 2.6
IC6009 15 0
IC6009 16 0
IC6009 17 2.6
IC6009 18 2.6
IC6009 19 0
IC6009 20 3
IC6010 1 3
IC6010 2 3
IC6010 3 0
IC6010 4 3
IC6010 5 3
IC6011 1 3
IC6011 2 3
IC6011 3 3
IC6011 4 0
IC6011 5 3
IC6011 6 3
IC6011 7 3
IC6011 8 3
IC6011 9 3
IC6011 10 0
IC6011 11 2.6
IC6011 12 2.6
IC6011 13 2.6
IC6011 14 2.6
IC6011 15 3
IC6011 16 2.6
IC6011 17 2.6
IC6011 18 2.6
IC6011 19 2.6
IC6011 20 3
IC6012 1 3
IC6012 2 3
IC6012 3 3
IC6012 4 3
IC6012 5 0
IC6012 6 3
IC6012 7 0
IC6012 8 3
IC6012 9 3
IC6012 10 0
IC6012 11 2.6
IC6012 12 2.6
IC6012 13 2.6
IC6012 14 2.6
IC6012 15 2.6
IC6012 16 2.6
IC6012 17 2.6
IC6012 18 2.6
IC6012 19 2.6
IC6012 20 3
IC9001 1 3
IC9001 2 0
IC9001 3 3
IC9001 4 -
IC9002 1 0.4
IC9002 2 0
IC9002 3 0.1
IC9002 4 0
IC9002 5 3
IC9004 1 3
IC9004 2 0
REF No. PIN No. POWER ON
IC9004 3 0
IC9004 4 0
IC9004 5 0
IC9004 6 3
IC9005 1 3
IC9005 2 0
IC9005 3 0
IC9005 4 0
IC9005 5 3
IC9006 1 0
IC9006 2 0
IC9006 3 0
IC9006 4 0
IC9006 5 3
IC9006 6 0
IC9007 1 3.5
IC9007 2 0
IC9007 3 1.3
IC9007 4 5
IC9007 5 8.1
IC9008 1 3.1
IC9008 2 0
IC9008 3 3
IC9008 4 3.5
IC9801 1 3.4
IC9801 2 0
IC9801 3 3.4
IC9801 4 0
IC9801 5 3.4
IC9801 6 0
IC9901 1 4.8
IC9901 2 -
IC9901 3 0
IC9901 4 0
IC9901 5 0
IC9901 6 0
IC9901 7 0
IC9901 8 -
IC9901 9 0
IC9901 10 -
Q2700 1 0
Q2700 2 0.1
Q2700 3 0
Q2700 4 0.1
Q2700 5 0.2
Q2700 6 3.9
Q4401 E 0
Q4401 C 0
Q4401 B 0
Q4402 E 0
Q4402 C 0
Q4402 B 0
Q4403 E 0
Q4403 C 0
Q4403 B 0
Q4404 E 0
Q4404 C 0
Q4404 B 0
Q4405 E 0
Q4405 C 0
Q4405 B 0
Q4406 E 0
Q4406 C 0.2
Q4406 B 0.2
Q8001 S 0
Q8001 D 3
REF No. PIN No. POWER ON
Q8001 G 0
Q8002 E 0
Q8002 C 0
Q8002 B 0
Q9001 E 0
Q9001 C 0
Q9001 B 0
Q9002 E 0
Q9002 C 0
Q9002 B 0.7
Q9030 S 3
Q9030 D 3
Q9030 G 0.5
Q9070 E 4.8
Q9070 C 4.8
Q9070 B 4
Q9801 1 0
Q9801 2 0
Q9801 3 0
Q9801 4 0
Q9801 5 4.8
Q9801 6 4.8
Q9801 7 4.8
Q9801 8 4.8
Q9901 1 0
Q9901 2 0
Q9901 3 4.8
Q9901 4 0
Q9901 5 0
Q9901 6 4.8
QR2001 E 0
QR2001 C 0
QR2001 B 0
QR2701 E 0
QR2701 C 0.2
QR2701 B 4.6
QR2702 E 0
QR2702 C 0.1
QR2702 B 4.6
QR4401 E 3
QR4401 C 0.2
QR4401 B 3
QR8001 1 0
QR8001 2 3
QR8001 3 0
QR8001 4 3
QR8001 5 3
QR8001 6 0
QR8002 E 0
QR8002 C 0.1
QR8002 B 0
QR8003 1 0
QR8003 2 0
QR8003 3 0
QR8003 4 3
QR8003 5 3
QR8003 6 3
QR9004 E 0
QR9004 C 3
QR9004 B 0
QR9007 1 0
QR9007 2 0
QR9007 3 2.9
QR9007 4 0
QR9007 5 0
QR9007 6 2.9
REF No. PIN No. POWER ON
QR9008 E 0
QR9008 C 0
QR9008 B 2.9
QR9009 1 0
QR9009 2 3
QR9009 3 0
QR9009 4 0
QR9009 5 3
QR9009 6 0
QR9030 S 0
QR9030 D 0
QR9030 G 3
QR9070 E 0
QR9070 C 0
QR9070 B 3
QR9081 E 0
QR9081 C 0.1
QR9081 B 0
QR9501 E 0
QR9501 C 0.9
QR9501 B 0
REF No. PIN No. POWER ON
QR8501 1 0
QR8501 2 4.4
QR8501 3 0
QR8501 4 4.8
QR8501 5 4.4
QR8501 6 0
QR8502 E 0
QR8502 C 4.4
QR8502 B 0
S2.2. Power/Flash P.C.B.
