Panasonic DMC-G2KPP - S5.1.3. Main P.C.B. Address Information

S-44
S5.1.3. Main P.C.B. Address Information
Address Information
C.....Component Side
F......Foil Side
Integrated Circuit
IC2001 E-4 C
IC2704 I-12 C
IC3011 F-12 F
IC3021 H-12 C
IC3022 H-12 C
IC3031 H-12 F
IC3032 H-12 F
IC3041 G-12 C
IC3051 H-11 C
IC3061 H-12 F
IC3101 H-8 C
IC3201 H-10 C
IC4002 J-18 F
IC4003 K-18 F
IC5001 H-17 F
IC6001 G-15 F
IC6002 F-17 F
IC6003 G-14 F
IC6004 K-15 F
IC6005 G-9 F
IC6006 F-6 C
IC6007 I-16 F
IC6008 K-16 F
IC6009 E-15 F
IC6010 H-14 F
IC6011 K-17 F
IC6012 E-6 C
IC9001 G-4 C
IC9002 E-9 F
IC9004 F-13 F
IC9005 F-14 F
IC9006 F-12 F
IC9007 I-12 C
IC9008 G-10 F
IC9009 H-6 C
IC9081 F-14 C
IC9101 I-12 F
IC9801 I-10 F
IC9901 J-14 F
Transistor
Q2700 H-13 C
Q4401 J-18 F
Q4402 J-3 C
Q4403 I-3 C
Q4404 J-4 C
Q4405 I-4 C
Q4406 I-19 F
Q8001 H-4 C
Q8002 I-6 C
Q9001 E-10 F
Q9002 J-18 F
Q9030 G-14 C
Q9070 H-9 F
Q9801 I-11 F
Q9901 J-7 C
Transistor-resistor
QR2001 G-18 F
QR2701 H-13 C
QR2702 H-13 C
QR4401 J-19 F
QR8001 H-6 C
QR8002 I-6 C
QR8003 H-4 C
QR9003 J-6 C
QR9004 F-14 F
QR9007 I-4 C
QR9008 H-4 C
QR9009 I-4 C
QR9030 G-14 C
QR9070 I-9 F
QR9081 D-10 F
QR9501 H-18 C
Test Point
CC3001 H-11 C
CC3002 H-11 C
CC3003 H-11 C
CC3004 H-11 F
CC3011 F-12 F
CC3101 G-8 C
CC3201 I-11 C
CC3311 G-12 C
CC3312 I-8 C
CC4024 H-14 C
CC4025 H-13 C
CC4030 I-19 F
CC6001 E-5 C
CC9001 H-14 C
CC9002 I-12 C
CC9003 H-14 C
CC9004 D-14 C
CC9005 F-19 C
CC9006 D-14 C
CC9008 K-5 C
CC9009 K-5 C
CC9016 J-13 F
CC9017 H-11 F
CC9018 H-14 C
CC9019 H-14 C
CC9027 F-9 F
CC9028 G-9 F
CC9050 I-13 C
CL2001 E-19 F
CL2002 F-18 F
CL2003 F-18 F
CL2004 F-18 F
CL2006 F-3 C
CL2007 F-18 F
CL2008 F-4 C
CL2009 G-18 F
CL2010 E-19 F
CL3001 H-12 F
CL3002 G-13 F
CL3003 H-12 F
CL3103 H-9 C
CL3104 H-9 C
CL4002 J-17 F
CL4016 J-17 F
CL4019 J-17 F
CL4021 I-4 C
CL4022 I-4 C
CL4023 J-19 F
CL6001 F-19 C
CL6002 F-19 C
CL6004 E-5 C
CL6006 K-18 F
CL6007 E-6 C
CL6010 E-5 C
CL8001 H-6 C
CL8002 J-7 C
CL9001 H-18 C
CL9002 I-16 C
CL9003 H-16 C
CL9004 D-9 F
CL9050 I-16 C
CL9051 I-16 C
CL9052 H-18 C
CL9053 K-5 C
CL9054 K-5 C
CL9055 J-4 C
CL9101 J-12 F
RL2001 E-3 C
RL2002 K-3 C
RL3101 G-8 C
RL3102 G-8 C
RL3105 I-8 C
RL3106 G-9 C
RL3107 H-9 C
RL3108 H-9 C
RL3109 G-8 C
RL3110 I-10 C
RL3111 H-8 C
RL3112 G-8 C
RL3113 G-8 C
RL3114 G-8 C
RL3115 H-8 C
RL3206 I-10 C
RL3211 H-11 C
RL3212 H-11 C
RL3213 H-11 C
RL3215 I-10 C
RL3216 I-11 C
RL3217 I-10 C
RL4001 J-18 F
RL4002 K-18 F
RL4003 I-18 F
RL4004 J-18 F
RL4005 I-18 F
RL4006 I-18 F
RL4007 J-18 F
RL4008 J-18 F
RL4009 I-18 F
RL4010 I-17 F
RL5001 G-17 F
RL5002 G-17 F
RL5003 G-18 F
RL5004 G-18 F
RL5005 H-17 F
RL5006 H-17 F
RL5007 H-17 F
RL5008 G-18 F
RL6001 J-15 F
RL6002 I-15 F
RL6003 I-15 F
RL6004 J-15 F
RL6005 J-15 F
RL6010 I-17 F
RL6011 H-15 F
RL6012 H-15 F
RL6013 H-15 F
RL6014 H-15 F
RL6015 H-15 F
RL6016 H-16 F
RL6017 H-16 F
RL6018 H-16 F
RL6019 I-17 F
RL6020 H-16 F
RL9001 I-19 C
RL9104 I-12 F
RL9108 I-12 F
RL9109 I-12 F
RL9111 I-12 F
Connector
FP3901 I-8 C
FP3902 I-11 C
FP3903 F-8 C
FP3904 F-11 C
FP9001 G-13 C
FP9002 K-6 C
FP9003 I-5 C
FP9004 H-7 C
FP9007 I-17 C
FP9008 E-12 C
FP9009 K-4 C
FP9010 I-14 C
FP9011 I-13 C
FP9090 G-5 C
JK2001 F-19 F
JK2004 H-18 F
P3901 G-13 F
P9001 F-17 C
P9002 G-10 F
P9005 E-6 C
P9006 E-19 C
Fuse
F2001 F-4 C
Diode
D5001 G-4 C
D8001 H-4 C
D8003 I-5 C
D9001 E-10 F
D9002 J-5 C
Crystal Oscillator
X6001 H-17 F
X9101 J-11 F
Coil
L2001 E-5 C
L2002 F-18 F
L3011 G-12 F
L3012 G-12 F
L3051 G-11 F
L3052 H-11 F
L5001 G-4 C
L5002 H-4 C
L9001 E-14 C
LB2002 F-18 F
LB2003 F-4 C
LB2004 F-18 F
LB2007 F-18 F
LB2008 H-18 F
LB3111 H-13 F
LB3112 H-13 F
LB3113 H-13 F
LB3122 H-9 C
LB3211 G-11 C
LB3212 H-10 C
LB3213 G-11 C
LB3222 H-11 C
LB5001 G-3 C
LB5002 H-5 C
LB5003 H-5 C
LB5004 G-4 C
LB6001 E-15 F
LB9001 E-13 C
LB9002 E-13 C
LB9003 F-11 F
LB9004 F-11 F
LB9005 F-11 F
LB9006 F-11 F
LB9007 F-12 F
LB9008 F-12 F
LB9009 F-12 F
LB9010 F-12 F
Thermistor
TH3901 H-13 F
Filter
FL5001 H-18 F
FL5002 H-18 F
FL5003 G-18 F
Capacitor
C2001 E-5 C
C2002 F-5 C
C2003 E-4 C
C2004 E-4 C
C2005 G-18 F
C2701 J-12 C
C2702 H-13 C
C2710 H-13 C
C3011 F-12 F
C3012 G-12 F
C3013 F-12 F
C3014 G-12 F
C3021 H-12 C
C3022 H-11 C
C3023 H-12 C
C3024 H-11 C
C3031 H-11 F
C3032 H-11 F
C3033 H-12 F
C3034 H-12 F
C3037 H-12 F
C3041 H-12 C
C3042 G-11 C
C3051 H-12 C
C3052 H-11 C
C3053 G-11 F
C3054 H-12 F
C3055 G-12 F
C3056 G-12 F
C3061 G-12 F
C3062 G-13 F
C3101 I-8 C
C3102 I-8 C
C3103 I-8 C
C3104 I-9 C
C3105 I-9 C
C3106 I-8 C
C3111 H-13 F
C3112 H-13 F
C3113 H-13 F
C3114 H-13 F
C3115 H-13 F
C3116 H-13 F
C3117 G-9 C
C3118 H-13 F
C3122 H-9 C
C3201 G-11 C
C3202 G-10 C
C3203 G-11 C
C3204 G-10 C
C3205 G-10 C
C3206 G-10 C
C3211 H-9 C
C3212 H-11 C
C3213 I-10 C
C3214 G-11 C
C3215 G-11 C
C3216 H-9 C
C3217 I-10 C
C3218 G-11 C
C3222 H-11 C
C3911 H-13 F
C3912 I-13 F
C3913 I-13 F
C3914 I-13 F
C3915 I-13 F
C3916 I-13 F
C3917 I-13 F
C3918 I-9 C
C3922 I-12 F
C3923 I-11 F
C3924 I-11 F
C3925 I-11 F
C3926 I-11 F
C3927 I-12 F
C3931 F-13 F
C3932 F-14 F
C3933 F-13 F
C3934 F-14 F
C3935 F-14 F
C3936 F-13 F
C3937 F-13 F
C3938 G-9 C
C3942 F-11 F
C3943 G-11 F
C3944 G-11 F
C3945 G-11 F
C3946 F-11 F
C3947 F-11 F
C4001 J-18 F
C4002 I-17 F
C4003 I-17 F
C4004 J-18 F
C4005 J-18 F
C4006 J-17 F
C4007 J-17 F
C4008 J-17 F
C4009 J-17 F
C4010 J-17 F
C4011 I-17 F
C4012 J-18 F
C4013 K-18 F
C4014 I-17 F
C4016 K-18 F
C4017 I-18 F
C4018 I-18 F
C4019 I-17 F
C4020 I-17 F
C4021 I-17 F
C4025 J-18 F
C4401 J-4 C
C4402 J-4 C
C4403 K-18 F
C4404 J-18 F
C4405 J-3 C
C4406 I-3 C
C4407 J-4 C
C4408 J-18 F
C4409 I-18 F
C5001 G-17 F
C5002 F-4 C
C5003 H-4 C
C5004 G-17 F
C5005 G-17 F
C5006 G-4 C
C5011 H-4 C
C5016 G-18 F
C6001 H-5 C
C6002 E-16 F
C6003 F-6 C
C6004 F-6 C
C6005 H-5 C
C6006 F-7 C
C6007 H-6 C
C6008 G-17 F
C6009 H-17 F
C6010 H-16 F
C6011 H-6 C
C6012 E-6 C
C6013 F-5 C
C6014 G-5 C
C6015 F-7 C
C6016 H-17 F
C6018 H-6 C
C6019 F-17 F
C6020 F-6 C
C6022 F-17 F
C6023 G-9 F
C6024 F-17 F
C6025 H-5 C
C6026 G-9 F
C6028 I-17 F
C6029 I-17 F
C6030 H-16 F
C6031 I-15 F
C6032 J-17 F
C6034 J-15 F
C6035 E-6 C
C6036 J-18 F
C6038 I-14 F
C6039 K-17 F
C6040 E-15 F
C6042 H-6 C
C6043 F-7 C
C6044 F-5 C
C6045 F-14 F
C6046 G-8 C
C6047 J-17 F
C6048 H-15 F
C6049 I-15 F
C6050 J-16 F
C6054 J-16 F
C6055 F-16 F
C6056 E-15 F
C8001 H-4 C
C8002 H-5 C
C9001 H-4 C
C9002 J-7 C
C9004 F-5 C
C9005 J-5 C
C9006 F-5 C
C9008 J-5 C
C9009 F-13 F
C9010 E-13 C
C9011 E-13 C
C9012 H-16 C
C9013 I-18 C
C9014 G-14 C
C9015 G-14 C
C9016 G-14 C
C9017 J-6 C
C9018 I-6 C
C9020 I-18 C
C9022 K-5 C
C9024 F-13 F
C9025 F-12 F
C9026 F-13 F
C9027 H-6 C
C9028 G-6 C
C9029 G-10 F
C9031 G-14 C
C9033 F-4 C
C9034 H-9 F
C9035 I-11 C
C9036 I-12 C
C9037 F-10 F
C9038 I-11 C
C9040 H-6 C
C9041 J-18 F
C9042 H-4 C
C9043 F-12 F
C9047 F-13 C
C9048 F-13 C
C9049 F-14 C
C9050 D-14 C
C9051 D-14 C
C9053 E-14 C
C9055 D-14 C
C9056 E-14 C
C9057 E-9 F
C9058 E-9 F
C9059 E-10 F
C9060 I-13 C
C9070 I-9 F
C9080 F-14 C
C9081 F-14 C
C9082 F-14 C
C9083 E-14 C
C9084 E-14 C
C9090 F-13 F
C9091 I-18 C
C9092 H-14 C
C9101 J-11 F
C9102 J-11 F
C9103 J-11 F
C9105 J-12 F
C9106 I-12 F
C9107 J-13 F
C9108 J-13 F
C9109 J-12 F
C9110 I-11 F
C9801 J-10 F
C9802 G-11 F
C9901 J-14 F
C9902 J-13 F
CX6001 G-17 F
CX6002 E-18 F
CX6003 F-17 F
CX6004 F-17 F
Resistor
R2001 E-18 F
R2003 F-3 C
R2004 G-18 F
R2005 E-19 F
R2007 F-18 F
R2010 I-18 F
R2701 H-13 C
R2702 H-13 C
R2703 H-13 C
R2719 H-13 C
R2720 H-14 C
R2721 H-14 C
R2725 H-13 C
R3033 H-12 F
R3034 H-13 F
R3035 H-13 F
R3051 G-11 F
R3052 G-12 F
R3053 G-11 F
R3054 G-12 F
R3101 H-9 C
R3102 H-9 C
R3103 H-9 C
R3104 H-9 C
R3133 I-8 C
R3134 I-9 C
R3201 H-9 C
R3202 H-10 C
R3203 H-9 C
R3204 H-10 C
R3233 G-11 C
R3234 G-10 C
R4001 J-18 F
R4002 I-18 F
R4003 J-17 F
R4004 I-17 F
R4005 J-17 F
R4006 I-18 F
R4007 I-17 F
R4008 K-18 F
R4009 J-17 F
R4010 I-17 F
R4011 J-17 F
R4014 I-17 F
R4016 J-17 F
R4019 I-17 F
R4020 I-17 F
R4401 J-4 C
R4402 K-18 F
R4403 J-4 C
R4404 K-18 F
R4405 J-18 F
R4406 J-18 F
R4407 J-4 C
R4408 J-3 C
R4409 J-4 C
R4410 J-3 C
R4411 J-3 C
R4412 J-3 C
R4413 J-3 C
R4414 J-4 C
R4415 J-4 C
R4416 J-4 C
R4417 J-5 C
R4418 J-18 F
R4419 J-4 C
R4420 J-18 F
R4421 I-19 F
R5001 G-4 C
R5002 H-18 F
R5003 G-18 F
R5004 G-4 C
R5005 H-4 C
R5008 G-17 F
R5009 G-3 C
R5010 H-4 C
R5011 H-4 C
R5021 G-4 C
R6001 H-5 C
R6002 G-14 F
R6003 H-5 C
R6004 F-17 F
R6005 F-17 F
R6006 H-17 F
R6007 H-16 F
R6008 H-16 F
R6009 G-17 F
R6010 H-5 C
R6012 F-5 C
R6013 G-17 F
R6015 F-16 F
R6016 F-4 C
R6017 K-17 F
R6018 E-6 C
R6020 F-5 C
R6021 F-17 F
R6022 F-17 F
R6023 F-4 C
R6025 G-6 C
R6026 F-6 C
R6027 F-6 C
R6029 F-14 F
R6030 F-16 F
R6032 H-5 C
R6034 F-17 F
R6035 F-15 F
R6036 H-5 C
R6039 G-14 F
R6040 F-4 C
R6044 F-16 F
R6045 F-16 F
R6046 K-17 F
R6047 F-5 C
R6049 K-5 C
R6050 H-15 F
R6051 H-5 C
R6057 H-15 F
R6059 F-6 C
R6060 J-17 F
R6062 H-9 F
R6065 G-6 C
R6066 G-9 F
R6067 G-9 F
R6070 F-15 F
R8001 J-6 C
R8002 H-3 C
R8003 H-6 C
R8005 H-6 C
R8006 H-4 C
R8007 I-5 C
R8008 I-5 C
R8009 H-5 C
R8010 H-5 C
R8011 I-6 C
R8012 J-7 C
R8013 J-6 C
R9001 I-4 C
R9002 I-18 C
R9003 J-6 C
R9004 J-7 C
R9005 J-5 C
R9006 J-5 C
R9007 J-6 C
R9008 J-5 C
R9010 J-6 C
R9012 J-6 C
R9013 H-12 C
R9014 G-12 C
R9015 H-12 C
R9016 H-12 C
R9017 H-13 C
R9018 G-13 C
R9019 H-18 C
R9020 G-13 C
R9021 H-5 C
R9022 F-11 F
R9023 F-12 F
R9024 F-11 F
R9025 H-14 C
R9026 I-4 C
R9027 H-4 C
R9028 G-19 C
R9029 F-14 C
R9030 H-6 C
R9031 F-13 C
R9032 F-14 C
R9033 I-18 C
R9036 J-3 C
R9037 H-13 C
R9038 G-14 C
R9039 F-5 C
R9040 I-18 C
R9041 J-18 F
R9042 J-18 F
R9043 H-14 C
R9044 H-14 C
R9045 F-6 C
R9046 H-6 C
R9047 F-14 F
R9048 H-3 C
R9049 J-18 F
R9050 G-19 C
R9051 E-6 C
R9052 F-6 C
R9053 H-6 C
R9054 F-5 C
R9055 H-5 C
R9056 F-5 C
R9057 I-7 C
R9058 I-6 C
R9059 H-6 C
R9060 G-13 C
R9061 G-14 C
R9062 H-5 C
R9063 F-4 C
R9065 I-6 C
R9066 I-6 C
R9067 I-6 C
R9068 G-14 C
R9069 G-4 C
R9070 F-14 C
R9071 I-9 F
R9072 H-9 F
R9073 H-14 C
R9074 H-6 C
R9075 F-14 C
R9080 G-10 F
R9081 G-10 F
R9082 F-14 C
R9083 F-14 C
R9084 E-14 C
R9085 E-14 C
R9086 E-13 C
R9087 D-13 C
R9088 E-9 F
R9089 D-9 F
R9090 D-9 F
R9091 E-9 F
R9092 E-9 F
R9093 F-10 F
R9094 E-9 F
R9095 E-10 F
R9096 F-13 C
R9097 F-13 C
R9098 F-13 C
R9099 H-14 C
R9101 I-12 F
R9102 I-11 F
R9104 J-12 F
R9105 J-12 F
R9106 J-12 F
R9107 J-12 F
R9108 I-11 F
R9109 J-11 F
R9113 I-11 F
R9114 I-12 F
R9501 H-18 C
R9502 F-14 C
R9803 H-9 F
R9804 H-9 F
R9805 I-10 F
R9806 J-10 F
R9807 I-10 F
R9808 J-10 F
R9904 J-7 C
R9905 J-7 C
RX6001 G-14 F
RX6002 H-14 F
RX6003 G-14 F
RX6004 H-14 F
RX6005 K-18 F
RX6006 G-14 F
RX6007 F-17 F
RX6008 E-17 F
RX6010 F-15 F
RX9001 F-11 F
RX9002 F-12 F
RX9003 F-14 C
RX9010 G-7 C
RX9011 F-7 C
RX9012 F-7 C
RX9013 F-6 C
Varistor
VA4001 K-5 C
VA5001 G-4 C
VA5002 H-4 C
VA5003 H-5 C
VA5004 G-3 C
VA5006 I-18 F
VA5007 I-18 F
VA5008 H-18 F
VA5009 H-18 F
VA5010 H-18 F
Main P.C.B. (1/2)
