2
Vol.2
Colour
[DMC-G2K]
(K)...........Black Type
(R)...........Red Type (except GD/GT/GN)
(A)...........Blue Type (except GD/GT/GN)
[DMC-G2W]
(K)...........Black Type
(R)...........Red Type (except GC/GH/GN)
(A)...........Blue Type (except GC/GH/GN)
[DMC-G2]
(K)...........Black Type
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General Guidelines ----------------------------------------3
1.2. Leakage Current Cold Check ---------------------------3
1.3. Leakage Current Hot Check (See Figure 1.)--------3
1.4. How to Discharge the E. Capacitor on POW
Flash P.C.B. -------------------------------------------------4
2Warning--------------------------------------------------------------5
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ----------5
2.2. How to Recycle the Lithium Ion Battery (U.S.
Only)-----------------------------------------------------------5
2.3. Caution for AC Cord (For EB/GC/GH)----------------6
2.4. How to Replace the Lithium Battery-------------------7
3 Service Navigation------------------------------------------------8
3.1. Introduction --------------------------------------------------8
3.2. Important Notice--------------------------------------------8
3.3. General Description About Lead Free Solder
(PbF) --------------------------------------------------------12
3.4. How to Define the Model Suffix (NTSC or PAL
model)-------------------------------------------------------13
4 Specifications ----------------------------------------------------16
5 Service Fixture & Tools ---------------------------------------17
5.1. Clean Box --------------------------------------------------17
5.2. Service Position ------------------------------------------18
6 Measurements and Adjustments --------------------------20
6.1. Matrix Chart for Replaced Part and Necessary
Adjustment-------------------------------------------------20
To Next Page
