19
CAUTION-1. (When servicing POW FLASH P.C.B.)
1. Be sure to discharge the capacitor on POW FLASH P.C.B..
Refer to “HOW TO DISCHARGE THE CAPACITOR ON POW FLASH P.C.B.”.
The capacitor voltage is not lowered soon even if the AC Cord is unplugged or the battery is removed.
2. Be careful of the high voltage circuit on POW FLASH P.C.B..
3. DO NOT allow other parts to touch the high voltage circuit on POW FLASH P.C.B..
To Next Page
