23
DVD Recorder
Connecting a Set Top Box, satellite receiver, decoder
You can connect a Set Top Box to receive digital terrestrial signals (DVB-T),
a Satellite receiver (digital / analogue) or a decoder for decrypting programmes.
Disconnect the power from all units.
Connect the external device with a 21-pin Scart cable to the AV2 connection
of the DVD Recorder.
1
Connect the DVD Recorder and the external device to the power supply.
2
21-pin Scart socket
21-pin Scart cable
AC mains lead
AV2
1
1
2
2
External device
External devices
Changing the settings in the SETUP menu when connecting a decoder
!
Press FUNCTIONS in stop mode.
!
Use to select [To Others] and confirm with ENTER.
!
Use to select SETUP and confirm with ENTER.
!
Use to select [Connection], , to select [AV2 Settings] and confirm
with ENTER.
!
In the next screen, use to select [AV2 Connection] and confirm with ENTER.
!
Use to select [Decoder (D/H) (DVD / HDD) or (VHS)] and confirm with ENTER.
!
Press RETURN and use to return to [Connection].
= Extra equipment for the connections shown
!
Use to select [Tuning], , to select [Manual] and confirm with ENTER.
!
Use to select an encrypted station and press ENTER.
!
In the Manual Tuning sub-menu, use to select [Decoder] and ,
to select [On].
!
Confirm the setting with ENTER.
107
HDD/DVD OUT
Tuning
Disc
Sound
Display
SETUP
AV2 Settings
Connection
AV2 Input
RGB/Video
AV2 Connection
Ext
Ext Link
AV2 Connection
Decoder (D/H) (DVD / HDD)
Decoder (VHS)
RETURN
SELECT
ENTER
Ext
Others
95
8
16
17
Pos
Name
8
95
16
17
18
19
Pos
Name
Channel
Fine Tuning
Manual
Tuning
1
ARD
Auto
7
Decoder
Audio Mode
RETURN
CHANGE
ENTER
On
BG
Mono
Off
Title Page
301
Tuning
Manual
Video System
PAL
AC IN~
AC mains lead
AV-Link function
To switch between television reception and signal from the DVD recorder.
!
DVD recorder signal: Press 0 + ENTER. DVD appears in the display.
!
Television reception: Press the buttons again. TV appears in the display
E
E
