Reference
TQBS0149
99
Specifications
Specifications are subject to change without
notice.
∫ General
Dimensions: 430 mm (W)
62 mm (H)
(including the projecting parts)
210 mm (D)
Mass: Approx. 3.2 kg
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: Approx. 46 W
Power consumption in networked standby
mode:
“Quick Start” is not activated and
“Networked Standby” is set to “On”
Approx. 2 W
Power consumption in standby mode:
“Quick Start” is not activated,
“Networked Standby” is set to “Off” and
“RF OUT ( CATV Signal )” or
“RF OUT ( Aerial Signal )” is set to “Off”
Approx. 0.3 W
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH
(no condensation)
∫ TV system
Tuner System: DVB-C, DVB-T/DVB-T2
Country:
Denmark, Sweden, Norway, Finland
Channel coverage: VHF: 5 - 12
UHF: 21 - 69
CATV: S1 - S20 (M1 - U10) 7 MHz Band
D051 - D073
D113 - D858
∫ Output terminal
Digital Audio out (coaxial): 1 pc.
HDMI out (19 pin type A): 1 pc.
∫ Internal HDD capacity
1TB
∫ Other terminals
USB Port (Type A)
Front: 1 pc., DC 5 V, Max. 900 mA
[Super-Speed USB (USB 3.0)]
Rear: 1 pc., DC 5 V, Max. 500 mA
[High-Speed USB (USB 2.0)]
Common Interface slot: 2 pcs.
LAN (Ethernet) Port: 1 pc.
10BASE-T/100BASE-TX
∫ Wireless LAN
Standard compliance: IEEE802.11a/b/g/n
Frequency range: 2.4 GHz/5 GHz band
Security
§
:
WPA
TM
/WPA2
TM
(Encryption type: TKIP/AES,
Authentication type: PSK)
WEP (64 bit/128 bit)
∫ LASER specification
Class 1 LASER Product
Wave length: 405 nm (BDs)
661 nm (DVDs)
783 nm (CDs)
Laser power:
§
This unit supports WPA
TM
and WPA2
TM
encryption.
No hazardous radiation is emitted with
the safety protection
DMR-UBC86EN_eng.book 99 ページ ２０１７年８月８日 火曜日 午前１１時１２分
