Panasonic DMR-XS350

What are the connections and controls on the
recorder?
Connections
Page 9
Controls
12. AV3 (s-video/composite) input terminals6. SD card slot
11. PLAY button5. DV IN terminal
10. STOP button4. OPEN/CLOSE disc tray
9. REC button to start recording3. Recording indicator (REC1, REC2)
8. Channel select buttons2. Blue LED (DMR-BS850/750 only)
7. USB port1. STANDBY (on/off) switch
6. COMPONENT VIDEO output terminals
11. COAXIAL digital audio output5. AV2 (EXT) SCART input/output terminal
10. OPTICAL digital audio output4. AV1 (TV) SCART input/output terminal
9. S-VIDEO output terminal3. LAN terminal
8. AV4 (s-video/composite) input terminals2. HDMI AV output terminal
7. AUDIO/VIDEO (composite) output terminals1. Satellite input terminals
1 2 3 4 5 6 7 8 9 10 11
1 2 3 4
5 6 7 8 9 10 11 12
