482
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
2. Saddle Stitch Unit
Fig. 1-004
[1] Guide Plate [2] Paper Folding Roller
[3] Delivery Guide Plate [4] Holding Roller
[5] Stitcher (Front, Rear) [6] Inlet Roller
[7] No. 1 Flapper [8] No. 2 Flapper
[9] Stitcher Mount [10] Butting Plate
[11] Crescent Roller [12] Paper Positioning Plate
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
