Panasonic EAIRC-MJ Series Service Manual

1 - 17
1
Mini VRF SYSTEM
Control Functions
9. Indoor Special Control
Mini VRF SYSTEM
Control Functions
EEPROM setting of drain pump in main outdoor unit
CODE: 0C
Indoor unit under this controlSetting No. Description
0 Invalid
All units
(Mode, Operation / Stop
Thermostat ON / OFF
doesn't concern)
1 DP operates for 20 minutes and stops for 2 hours
2 DP operates for 20 minutes and stops for 20 minutes
3 DP always operates
4
DP operates for XX minutes when indoor unit's operation
changes;
from thermostat ON
thermostat OFF or operation stopped.
Cooling mode
Dry mode
Heating mode
5
DP operates for XX minutes when indoor unit's operation
changes;
from thermostat ON or thermostat OFF
operation stopped.
6 Both Setting No. 4 and 5 functions.
7
(Factory
preset
mode)
DP operates for XX minutes when indoor unit's operation
changes
from thermostat ON or thermostat OFF
operation stopped.
Cooling mode
Dry mode
*When setting No. 4 – 7 is selected, this function works only for below indoor unit types.
Types : F1, F2, M1, E1
*Operating time mentioned “XX” above is able to set in EEPROM of the main outdoor unit
9. Indoor Special Control
EEPROM setting in main outdoor unit
CODE: 2B
Setting No. XX
20
30
40
50
60
20 minutes
30 minutes (factory preset mode)
40 minutes
50 minutes
60 minutes
* The drain pump always operates when the indoor unit is thermostat ON in cooling operation.
* Once the drain pump operates, it keeps operating for 20 minutes.
In the above 2 cases, the drain pump operates by the signal of indoor PCB, not by CCU.
9-4. Drain Pump control
CCU intervenes in drain pump control of the indoor unit according to the setting in EEPROM in the outdoor unit.
The drain pump operates from CCU control at the following condition.
- DP counter 5
* The DP counter counts each oil recovery control.
- Liquid temperature (E1) in the indoor unit which selected cooling mode < 0 °C
* Regardless of operating / stopped.
- Low Silhouette Ducted type indoor unit
In Low Silhouette Ducted types, dirt might be accumulated when water collects in the drain pan for a long
term. Therefore, the drain pump works longer to drain water surely.
* To activate this function, it is necessary to set it to EEPROM on the main outdoor PCB.
