Panasonic EAIRC-MJ Series Service Manual

2 - 13
2
Mini VRF SYSTEM
Outdoor Unit Repair Procedures
6. Pumping Out Refrigerant from Outdoor Unit
2- 17
2
To determine the completion of refrigerant recovery, follow the instructions that came with the refrigerant recovery
unit.
NOTE
Manifold
gauge
Lo Hi
Connect from here to
refrigerant recovery unit
Fig. 2-8
7. Pumping Out Refrigerant from Outdoor Unit
Mini VRF SYSTEM
Outdoor Unit Repair Procedures
Low-pressure outlet port
(For ø7.94 mm connector)
SM830195-04_Mini VRF SYS.indb 13 15/01/08 18:35:47
