EN52
Specifications
Power supply AC 220 V 50 Hz
Power consumption
135 W
(Approx. 0.3 W when the controller is “OFF”)
Upper body massage
Massage area
(Up-Down)
Approx. 79 cm (The massage heads move a total of approx. 63 cm)
Massage area
(Left-Right)
Distance between massage heads during operation (including width of massage heads)
Neck, shoulder, back: Approx. 5 cm ~ 21 cm
Lower back/hip: Approx. 5 cm ~ 25 cm
Distance between massage heads (including width of massage heads) during back roll
and up-and-down movement: Approx. 5 cm ~ 17 cm
Massage area
(Forward-Back)
Projected range of massage head travel (intensity adjustment): Approx. 10 cm.
Massage speed
Knead: From approx. 4 times/min ~ approx. 73 times/min
Tap: From approx. 190 times/min ~ approx. 520 times/min (one side)
Moving speed: From approx. 1 cm/sec ~ approx. 5 cm/sec
Air massage
Air pressure
(Calf)
3: Approx. 35 kPa
2: Approx. 32 kPa
1: Approx. 17 kPa
(May vary with the area slightly.)
Sole massage
section
Massage speed From approx. 8 times/min ~ approx. 21 times/min
Reclining angle
Backrest: Approx. 120 ° ~ 170 °
Legrest (Leg & sole massage section): Approx. 5 ° ~ 85 °
Automatic shut - of f Up to about 19 minutes (automatically ends)
Dimensions
When not reclined
(D × W × H)
Approx. 130 cm × 90 cm × 115 cm
When reclined
(D × W × H)
Approx. 200 cm × 90 cm × 72 cm
Weight of unit Approx. 87 k
g
Dimensions of box
(D × W × H)
Approx. 170 cm × 75 cm × 77 cm
Weight in box Approx. 108 k
g
Maximum user weight 120 k
g
Applicable standard
GB4706.1
GB4706.10
The product works well for people weighing under 120 k
g
. But for persons weighing 100 k
g
or more, the product operations may
make more noise and the fabric cover may wear faster.
