EP3513
ORDER NO.HPD0509U24C1
- 2 -
CONTENTS
Page
1 COMPONENTS IDENTIFICATION…………………………………………………………………………………………………………………………3
2 MASSAGE RANGE（MOVEMENT RANGE OF MASSAGE WHEELS）………………………………………………………………………………5
3 TURNING ON THE POWER………………………………………………………………………………………………………………………………6
4 REQUIRED TOOLS…………………………………………………………………………………………………………………………………………7
5 DISPLAY METHOD OF MASSARG BLOCK TOTAL USE TIME AND OPERATION TIME…………………………………………………………8
6 DISASSEMBLY………………………………………………………………………………………………………………………………………………12
7 ACTUAL WIRING DIAGRAM……………………………………………………………………………………………………………………………52
8 CHECKING…………………………………………………………………………………………………………………………………………………55
9 GREASE……………………………………………………………………………………………………………………………………………………60
10 EXPLODED VIEW…………………………………………………………………………………………………………………………………………63
11 REPLACEMENT PARTS LIST……………………………………………………………………………………………………………………………70
