Panasonic EP790-C1 - Assembling Procedure

15.4.2 Assembling Procedure
TOP PREVIOUS NEXT
(see Figures top and middle)
1. Fit the tapping gear box side plate to the shaft of tapping shaft assembly.
2. Fit the E type stop ring to the shaft.
3. Fit the tapping gear box A to the shaft.
4. Check the direction of tapping clutch lead wire outlet, and install the tapping clutch.
5. Install the tapping gear box B
6. Fix with the tapping gear box assembling screw (Bind,TP,B3-20)
•@
