Parts identication
A
B C
D
E
Back
















a
c
b
d


A
Main body
1 Protective cap
2 System outer foil
3 Foil frame
4 Power switch
5 Lamp display
a. Shaving sensor
lamp (
)
b. Battery capacity
lamp ( )
c. Switch lock lamp ( )
d. Charge status lamp
( )
6 Appliance socket
7 Foil frame release
buttons
8 Outer foil section
9 Inner blades
 Trimmer
 Trimmer handle
 System outer foil
release buttons
B
AC adaptor (RE7-87)
 Adaptor
 Power plug
 Appliance plug
 Cord
C
Length adjustment
comb attachment (1 mm
(1/32˝ ) to 3 mm (1/8˝ ))
ES-LL41
 Comb attachment
release buttons
D
Length adjustment
comb attachment (5 mm
(3/16˝ ) to 7 mm (9/32˝ ))
ES-LL41
 Comb attachment
release buttons
Accessory
E
Oil
