Before startup
Install the 2 in 1 HEPA composite and deodorizing filter
2
Take out the 2 in 1
HEPA composite and
deodorizing filter
from the poly bag.
Remove the front panel.
Front panel
Pull it forward
with both hands.
Remove the 2 in 1 HEPA composite
and deodorizing filter.
2 in 1 HEPA composite and
deodorizing filter
Pull it
forward.
Take out the 2 in 1 HEPA composite
and deodorizing filter from the poly
bag.
Poly bag
1
Write down the
installation date
on the label.
Replacement humidifying filter
Attention
Be sure to read P.4, 6,
8 before installation.
Preparation
3
Install the 2 in 1
HEPA composite and
deodorizing filter
and the front panel.
Install the 2 in 1 HEPA
composite and deodorizing filter.
(Install in the correct direction.)
Place the [FRONT SIDE] side
forward and place into the
concave portion of the product.
2 in 1 HEPA composite and
deodorizing filter
Install the front panel.
Be sure to attach the
front panel before use.
