Basic Instructions
2 − 69
4. When X0 is in the on state, the BRK instruction is executed and program execution stops.
5. Press the “F3” key while holding down the “Shift” key in the MONITOR & TEST RUN window of
the programming tool software to continue the program execution.
If a BRK instruction is executed, program execution stops.
Execution
(BRK)
35
X12
13
X1 Y31
Stops at the address 35
Starts from the address 13
6. Up to the end of the program, proceed according to the operation in steps 4 and 5 above.
If you want, change to the step operation mode, in which the program stops execution after
execution of each instruction.
