Table of Contents
xvi
F175 SPSH Pulse output (Linear interpolation) 3 − 542.......................
F175 SPSH Pulse output (Linear interpolation) 3 − 548.......................
F176 SPCH Pulse output (Circular interpolation) 3 − 553......................
Screen display instructions
F177 HOME Pulse output (Home return) 3 − 557.............................
F178 PLSM Input pulse measurement 3 − 561...............................
F180 SCR FP−e screen display registration 3 − 565.........................
F181 DSP FP−e screen display switching 3 − 568...........................
F182 FILTR Time constant processing 3 − 569...............................
Basic function instruction
F183 DSTM Auxiliary timer (32-bit) 3 − 571..................................
Data transfer instructions
F190 MV3 Three 16-bit data move 3 − 575.................................
P190 PMV3
F191 DMV3 Three 32-bit data move 3 − 577................................
P191 PDMV3
Logic operation instructions
F215 DAND 32-bit data AND 3 − 579.......................................
P215 PDAND
F216 DOR 32-bit data OR 3 − 581........................................
P216 PDOR
F217 DXOR 32-bit data XOR 3 − 583.......................................
P217 PDXOR
F218 DXNR 32-bit data XNR 3 − 585.......................................
P218 PDXNR
F219 DUNI 32-bit data unites 3 − 587......................................
P219 PDUNI
F230 TMSEC Time data
Second conversion 3 − 589........................
P230 PTMSEC
F231 SECTM Second
Time data conversion 3 − 591........................
P231 PSECTM
Data conversion instructions
F235 GRY 16−bit data → Gray code 3 − 593...............................
P235 PGRY
F236 DGRY 32−bit data → Gray code 3 − 594...............................
P236 PDGRY
F237 GBIN 16−bit Gray code → 16−bit binary data 3 − 595...................
P237 PGBIN
