High−level Instructions
3 − 9
Application example
Example 1: Transfer K30 to timer set value area SV0 when R1 turns on.
F0 MV, K 30, SV 0
R1
Example 2: Transfer the timer elapsed value EV0 to data register DT0 when
R2 turns on.
F0 MV, EV 0, DT 0
R2
Flag conditions
・Error flag (R9007): Turns on and stays on when the area specified using the index modifier
exceeds the limit.
・Error flag (R9008): Turns on for an instant when the area specified using the index modifier
exceeds the limit.
