High−level Instructions
3 − 16
Outline The head word No. of the specified slot is read.
This function is available from FP2/FP2SH Ver. 1.50 or later.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
10
F4 GETS , DT11 , DT 20
S
D
Trigger
R0
10
11
ST R 0
F 4 (GETS)
DT 11
DT 20
S Specification of slot numbers
D Area in which the WX and WY numbers stored (32 bits)
Operands
O
p
erand
Relay Timer/Counter Register
Index
register
Constant
Index
modifier
Operand
WX WY WR WL SV EV DT LD FL I K H
modifier
S A A A A A A A A A A N/A N/A A
D N/A A A A A A A A A A N/A N/A A
Explanation of example
The number of WX and WY for the slot specified by S is read, and set in [D, D+1].
Head number of WX of specified slot
D
D+1
Head number of WY of specified slot
When the unit is with X only, the same value is stored for the head number of WY.
When the unit is with Y only, the same value is stored for the head number of WX.
When the unit without input/output is specified, the same value is stored in D and D+1.
Flag conditions
・Error flag (R9007)(R9008):
− It turns on, when the specified address using the index modifier exceeds a limit.
− It turns on, when the number other than 0 to 31 is specified for the slot number.
F4
P4
Reading of head word No.
of the specified slot.
(GETS)
(PGETS)
A: Available
N/A: Not Available
