1.1 Table of Relays, Memory Areas and Constants
1-5
Item Number of
points
Memory area available for use
Matsushita IEC
Function
External input relay
(see note 3)
6 double
words
DWX0−DWX11 %ID0−
%ID11
Code for specifying 32 external
input points as a double word
(32 bits) of data.
4
)
External output relay
(see note 3)
6 double
words
DWY0−DWY11 %QD0−
%QD11
Code for specifying 32 external
output points as double word
(32 bits) of data.
e
e note 4
)
Internal relay
(see note 2)
31 double
words
DWR0−DWR61 %MD0.0−
%MD0.61
Code for specifying 32 internal
relay points as double word
(32 bits) of data.
w
ord) (se
e
Data register
(see note 2)
830 double
words
DDT0−
DDT1658
%MD5.0−
%MD5.1658
Data memory used in a
program. Data is handled in
32-bit units (double word).
a
(double
w
Timer/counter set
value area
72 double
words
DSV0−DSV142 %MD3.0−
%MD3.142
Data memory for storing a
target value of a timer and an
initial value of a counter. Stores
by timer/counter number.
M
emory are
a
Timer/counter
elapsed value area (see
note 2)
72 double
words
DEV0−DEV142 %MD4.0−
%MD4.142
Data memory for storing the
elapsed value during operation
of a timer/counter. Stores by
timer/counter number.
M
e
Special data
register
56 double
words
DDT9000−
DDT9110
%MD5.9000−
%MD5.9110
Data memory for storing
specific data. Various settings
and error codes are stored.
Index register 1 double
words
DI0 %MD6.0 Used as an address of
memory area and constants
modifier.
Item Number of points
oint
Master control relay points (MCR) 32 points
t
ion p
o
Number of labels (JP and LOOP) 64 labels
n
struct
i
Number of step ladders
128 stages
trol in
s
Number of subroutines
16 subroutines
Cont
r
Number of interrupt programs
7 programs (external: 6, internal: 1)
Item Range available for use
g
Matsushita IEC
Decimal constants K−32768 to K32767 (for 16-bit operation) −32768 to 32767 (for 16-bit operation)
K−2147483648 to K2147483647
(for 32-bit operation)
−2147483648 to 2147483647
(for 32-bit operation)
a
nt
Hexadecimal
constants
H0 to HFFFF (for 16-bit operation) 16#0 to 16#FFFF (for 16-bit operation)
Consta
n
constants
H0 to HFFFFFFFF (for 32-bit operation) 16#0 to 16#FFFFFFFF (for 32-bit
operation)
C
Floating point type
F−1.175494×10
−38
to F−3.402823×10
38
−1.17549410E−38 to −3.402823E38
F1.175494×10
−38
to F3.402823×10
38
1.17549410E−38 to 3.402823E38
