High−level Instructions
3 − 38
Description
S2 words of data stored in the IC card expansion memory area starting from S1 are transferred into the CPU
memory location specified by D.
Precautions during programming
The values available for S1 and S2 vary depending on the size of the IC card expansion memory area.
When using an nkB IC card
Value that can be specified for S2: 1 to
n x 1024
2
−1
)
(
Value that can be specified for S1: 0 to ([S2]−1)
n S1 S2
256 k K131070 K131071 (H1FFFF)
512 k K262142 K262143 (H3FFFF)
1M K524286 K524287 (H7FFFF)
2M K1048574 K1048575 (HFFFFF)
Note: When using as remaining DOS formatted mkB expansion memory:
S2: 1 to
m x 1024
2
)(
S1: 0 to [S2]
Flag conditions
・Error flag (R9007): Turns on and stays on when:
・Error flag (R9008): Turns on for an instant when:
− No IC card is installed in the CPU.
− The IC card access enable switch is set to off (disabled).
− No expansion memory area is found on the IC card.
− The address specified by S1 does not exist in the expansion memory area
of the IC card.
− The area specified by S2 exceeds the limit of the expansion memory area
of the IC card.
− The area is exceeded when blocks specified by D and subsequent
parameters are transferred.
FP2SH/FP10SH
