1.1 Table of Relays, Memory Areas and Constants
1-9
1.1.3 FPΣ
12k type
Item Number
of points
Memory area available for use Function
External input relay
(see note 1)
FPG−C32T/C32TTM
512 X0−X31F
Turns on or off based on
external input.
External input relay
(see note 1)
FPG−C32T2/C32T2TM
FPG−C24R2/C24R2TM
FPG−C28P2
1184 X0−X73F
External output relay
(see note 1)
FPG−C32T/C32TTM
512 Y0−Y31F
Externally outputs on or off state.
e
lay
External output relay
(see note 1)
FPG−C32T2/C32T2TM
FPG−C24R2/C24R2TM
FPG−C28P2
1184 Y0−Y73F
Rel
Internal relay
(see note 2)
1568 R0−R97F Turns on or off only within a
program.
Link relay
(see note 2)
1024 L0−L63F Shared relay used for PLC link.
Timer
(see notes 2
and 3)
1024 T0−T1007/C1008−C1023 Goes on when the timer reaches
the specified time.
Corresponds to the timer
number.
Counter
(see notes 2
and 3)
1024 C1008−C1023/T0−T1007 Goes on when the counter
increments.
Corresponds to the counter
number.
Special internal relay 176 R9000−R910F Turns on or off based on specific
conditions. Used as a flag.
External input relay
(see note 1)
FPG−C32T/C32TTM
32 words WX0−WX31
Code for specifying 16 external
input points as one word (16
bits) of data.
External input relay
(see note 1)
FPG−C32T2/C32T2TM
FPG−C24R2/C24R2TM
FPG−C28P2
74 words WX0−WX73
)
w
ords)
External output relay
(see note 1)
FPG−C32T/C32TTM
32 words WY0−WY31
Code for specifying 16 external
output points as one word (16
bits) of data.
mory area (w
o
External output relay
(see note 1)
FPG−C32T2/C32T2TM
FPG−C24R2/C24R2TM
FPG−C28P2
74 words WY0−WY73
)
Me
m
Internal relay
(see note 2)
98 words WR0−WR97 Code for specifying 16 internal
relay points as one word (16
bits) of data.
Link relay 64 words WL0−WL63 Code for specifying 16 link relay
points as one word (16 bits) of
data.
