Outline Converts 16-bit data to ASCII code that expresses the equivalent
decimals.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P75 (PBINA)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F75 BINA , DT 0 , K 6 , DT 50
S1
D
Trigger
S2
R0
10
11
ST R 0
F75 (BINA)
DT 0
K6
DT 50
S1 16-bit equivalent constant or 16-bit area to be converted (source)
S2 16-bit equivalent constant or 16-bit area to specify number of bytes used to
express destination data (ASCII codes)
D Starting 16-bit area for storing ASCII codes (destination)
Operands
modifier
S1 A A A A A A A A A A A A A A
S2 A A A A A A A A A A A A A A
D N/A A A A A A A A A N/A N/A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F75
P75
(PBINA)
(BINA)
16-bit binary data → ASCII code
A: Available
N/A: Not Available
