High−level Instructions
3 − 212
Outline Extracts the lower 4 bits (bit positions 0 to 3) of the specified 16-bit
areas and combines them into one word.
For the FP0R/FPΣ/FP−X/FP0/FP−e, the P type high−level instruction
“P93 (PUNIT)” is not available.
Program example
Boolean
Ladder Diagram
Address Instruction
10
F93 UNIT, DT10, K 3 , DT 20
S
D
Trigger
R20
n
10
11
ST R 20
F 93 (UNIT)
DT 10
K3
DT 20
S Starting 16-bit area to be extracted (source)
n 16-bit equivalent constant or 16-bit area to specify number of data to be extracted
D 16-bit area for storing combined data (destination)
Operands
modifier
S A A A A A A A A A N/A N/A N/A N/A A
n A A A A A A A A A A A A A A
D N/A A A A A A A A A A A N/A N/A A
(*1) This cannot be used with the FP0 and FP−e.
(*2) This cannot be used with the FP0, FP−e, FP0R, FPΣ, FP−X.
(*3) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is I0 to IC.
(*4) With the FP0R, FPΣ,FP−X, FP2, FP2SH, and FP10SH, this is ID.
F93
P93
(PUNIT)
(UNIT)
16-bit data combine
A: Available
N/A: Not Available
