Panasonic FV-30BW2H - Supplied Accessories

6
In extreme weather condition(rainfall precipitation more than 240 mm/h. wind speed
higher than No.8 typhoon.), there may be water through frame into bathroom.
When you install plastic part, do not exert too much strength to fixing the screw,
otherwise, the product would be damaged.
Do not install this product in a public bath room.
Do not install this product in a wardrobes.
請勿把本產品安裝在公共浴室。
請勿把本產品安裝在衣櫃內。
在極端惡劣的天氣條件下(雨量大於240 mm/h，風速大於8號風球)，可能會有水通過產品框架
進入浴室內部。
安裝塑料部件時，為了不損壞產品，鎖螺絲時請注意不要用力過大。
Product warranty registration
產品保修登記
Do not cover air outlet, maybe it can cause breakdown.
請勿覆蓋產品出風口，否則可能會引起機體故障。
安裝要求
INSTALLATION REQUIREMENTS
SUPPLIED ACCESSORIES
Installationandoperatinginstructions
Louver assembly
Remote control assembly
R03(AAA) Carbon battery
No.
Drawing
Nameandpurpose
Machinescrew(M4×10,usedtoinstallthelouver assembly)
1
1
1
1
1
2
2
4
Self-tappingscrew( 4×16,usedtoinstallthecontroller
holder) (placed on the backside of controller holder)
Self-tappingscrew( 4×25,usedtoinstallthe
mainbodyandthewindow)
Qty
面板組合
遙控器組合
R03(AAA)碳性電池
名稱及用途
安裝使用說明書
機械螺絲(M4×10用於面板 組合安裝)
自攻螺絲( 4×25用於機 體與窗體 的安裝)
圖樣
代號
數量
自攻螺絲( 4×16用於遙 控器底座 安裝)(放置 於遙控器 底座背面)
包裝附件清單
