Setting up the monitor unit
Battery installation
R USE ONLY the specified battery.
1 Remove the screw from the battery cover.
2 Remove the battery cover.
3 I
nsert the battery.
4 Insert the tabs (A) into the slots, and
then close the battery cover (B).
5 Drive the screw into the battery cover.
R Follow the directions on the display
to set up the unit.
Battery charging
1 Insert the AC adaptor plug (A) firmly into
the monitor unit’s micro-USB connector.
2 Connect the AC adaptor (B) to the power
outlet.
Charge for about 8 hours.
Note:
R Use only the supplied AC adaptor
S006AKU0500100.
R When the AC adaptor plug is connected to
the monitor unit’s micro-USB connector,
is displayed on the screen.
R It is normal for the monitor unit to feel warm
during charging.
R The monitor unit resets if the AC adaptor is
disconnected when charging.
14
For assistance, visit www.panasonic.ca/english/support
Getting Started
