Useful Information
46 For assistance, please call 1-800-211-PANA (7262).
Charger unit (KX-TG5422 and KX-TG5423 only)
The charger can be wall mounted, as shown below.
1 Connect the AC adaptor.
2 Drive the screws (not included) into the wall using the wall mount template (see below).
3 Mount the charger (1).
4 Slide it down (2) and to the right (3) until it is secure.
1
2
3
25.4 mm
Screws
To power
outlet
(1")
Wall mount template for the charger
25.4 mm
(1")
