Panasonic lumix DC-TZ90 Basic Operating Instructions

16
DVQX1246 (ENG)
Basics
Basic operations
Holding the camera
• Do not block the flash, AF Assist Lamp, microphone,
or speaker with your fingers or other objects.
Flash/AF Assist Lamp
Microphone
Speaker
Adjusting the angle of the monitor
• Be careful not to catch your finger, etc. in the
monitor.
• When rotating the angle of the monitor, be careful
not to apply too much force. Doing so may cause
damage or malfunction. (Open and close with your
finger on point
.)
• When not using this camera, close the monitor
completely back to the original position.
[LVF] button (Recording pictures using the viewfinder)
1
Press [LVF] button
Automatic switching between
viewfinder and monitor
Viewfinder display Monitor display
●
For automatic switching between the viewfinder and monitor, the eye sensor
automatically switches the display to viewfinder when your eye or an object
moves close to the viewfinder.

Panasonic lumix DC-TZ90 Specifications

General

Sensor	1/2.3-inch High Sensitivity MOS Sensor
Effective Pixels	20.3 Megapixels
Lens	LEICA DC VARIO-ELMAR
Dimensions	112.0 x 67.3 x 41.2 mm
Focal Length	4.3 - 129mm (24 - 720mm in 35mm equivalent)
Aperture	F3.3 - F6.4
ISO Sensitivity	80-3200 (expandable to 6400)
Display	3.0-inch TFT Screen LCD Display (1040K dots)
Viewfinder	0.2-inch EVF (1166K dots)
Video Recording	4K UHD (3840x2160) at 30p/25p
Connectivity	Wi-Fi
Battery Life	Approx. 380 shots (CIPA standard)
Weight	Approx. 322g with Battery and SD Memory Card
Storage Media	SD/SDHC/SDXC memory card
Image Stabilization	5-axis Hybrid O.I.S. (Optical Image Stabilizer)
